Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
12
SRF-M37
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
* A-3347-451-A KEY BOARD, COMPLETE
********************
1-694-972-11 CONDUCTIVE BOARD, CONNECTION
3-247-146-01 HOLDER (LCD)
< CAPACITOR >
C101 1-115-156-11 CERAMIC CHIP 1uF 10V
C102 1-125-701-11 DOUBLE LAYER 0.047F 5.5V
C103 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C104 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C105 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C107 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C109 1-126-157-11 ELECT 10uF 20% 16V
C110 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C111 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C112 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C113 1-115-156-11 CERAMIC CHIP 1uF 10V
C114 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C115 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C116 1-115-156-11 CERAMIC CHIP 1uF 10V
C117 1-115-156-11 CERAMIC CHIP 1uF 10V
C118 1-115-156-11 CERAMIC CHIP 1uF 10V
C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C120 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C121 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C122 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C123 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C124 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C125 1-115-156-11 CERAMIC CHIP 1uF 10V
C126 1-124-589-11 ELECT 47uF 20% 16V
C127 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C131 1-115-156-11 CERAMIC CHIP 1uF 10V
C132 1-115-156-11 CERAMIC CHIP 1uF 10V
C134 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C135 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C140 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C141 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C142 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< DIODE >
D101 8-719-071-34 DIODE RB521S-30-TE61
D102 8-719-988-61 DIODE 1SS355TE-17
D103 8-719-083-63 DIODE UDZSTE-1713B
D104 8-719-083-60 DIODE UDZSTE-174.7B
D105 8-719-083-60 DIODE UDZSTE-174.7B
< IC >
IC101 6-802-891-01 IC TC9329FA-123
IC102 8-759-690-96 IC XC61CN1002NR
IC103 6-701-978-01 IC XC61CN0802NR
< CONDUCTOR >
JC101 1-216-864-11 METAL CHIP 0 5% 1/16W
JC103 1-216-864-11 METAL CHIP 0 5% 1/16W
JC104 1-216-864-11 METAL CHIP 0 5% 1/16W
JC105 1-216-864-11 METAL CHIP 0 5% 1/16W
JC106 1-216-864-11 METAL CHIP 0 5% 1/16W
JC107 1-216-864-11 METAL CHIP 0 5% 1/16W
JC108 1-216-864-11 METAL CHIP 0 5% 1/16W
JC109 1-216-864-11 METAL CHIP 0 5% 1/16W
JC110 1-216-864-11 METAL CHIP 0 5% 1/16W
JC112 1-216-864-11 METAL CHIP 0 5% 1/16W
JC113 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L101 1-412-995-21 INDUCTOR 22uH
L102 1-412-995-21 INDUCTOR 22uH
L103 1-469-845-11 INDUCTOR 4.7uH
< LIQUID CRYSTAL DISPLAY >
LCD101 1-805-123-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q101 8-729-046-89 TRANSISTOR 2SB970-S(TX).S0
Q102 8-729-029-15 TRANSISTOR DTC144TUA-T106
Q103 8-729-026-52 TRANSISTOR 2SA1576A-T106-R
Q104 8-729-905-35 TRANSISTOR 2SC4081T106R
Q105 8-729-905-35 TRANSISTOR 2SC4081T106R
Q106 8-729-905-35 TRANSISTOR 2SC4081T106R
Q107 8-729-905-35 TRANSISTOR 2SC4081T106R
< RESISTOR >
R101 1-216-821-11 METAL CHIP 1K 5% 1/16W
R102 1-216-845-11 METAL CHIP 100K 5% 1/16W
R103 1-216-833-11 METAL CHIP 10K 5% 1/16W
R105 1-216-857-11 METAL CHIP 1M 5% 1/16W
R106 1-216-821-11 METAL CHIP 1K 5% 1/16W
R108 1-216-821-11 METAL CHIP 1K 5% 1/16W
R109 1-216-821-11 METAL CHIP 1K 5% 1/16W
R110 1-216-821-11 METAL CHIP 1K 5% 1/16W
R111 1-216-845-11 METAL CHIP 100K 5% 1/16W
R112 1-216-833-11 METAL CHIP 10K 5% 1/16W
KEY
