HCD-EP515
US Model
Canadian Model
AEP Model
UK Model
E Model
SERVICE MANUAL
MICRO HI-FI COMPONENT SYSTEM
Sony Corporation
Home Audio Company
Published by Sony Engineering Corporation
9-877-160-03
2003G16-1
© 2003.07
HCD-EP515 is the Amplifier, CD player, Tape
Deck and Tuner section in CMT-EP515.
SPECIFICATIONS
Ver 1.2 2003. 07
Model Name Using Similar Mechanism NEW
CD
CD Mechanism Type KSM-213EDP
Section
Base Unit Name BU-K7BD44B
Optical Pick-up Name KSS-213E/C2N
TAPE
Model Name Using Similar Mechanism NEW
Section
Tape Transport Mechanism Type CMAL1Z240A
CD player section
System Compact disc and digital
audio system
LaserSemiconductor laser
(
λ
=780 nm)
Emission duration:
continuous
Frequency response 2 Hz – 20 kHz (±0.5 dB)
Tape deck section
Recording system 4-track 2-channel stereo
Frequency response 50 – 13,000 Hz (±3 dB),
using Sony TYPE I
cassettes
Amplifier section
AUDIO POWER SPECIFICATIONS:
(U.S.A. model only)
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
With 6-ohm loads, both channels driven, from 120 -
10,000 Hz; rated 14 watts per channel minimum RMS
power, with no more than 10% total harmonic
distortion from 250 milliwatts to rated output.
North American model:
Continuous RMS power output (reference):
15 + 15 W
(6 ohms at 1 kHz, 10%
THD)
European model:
DIN power output (rated): 11 + 11 W
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
15 + 15 W
(6 ohms at 1 kHz, 10%
THD)
Music power output (reference):
25 + 25 W
Other models:
The following measured at AC 230 V or AC 120 V, 50/
60 Hz
DIN power output (rated): 11 + 11 W
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
15 + 15 W
(6 ohms at 1 kHz, 10%
THD)
Inputs
MD IN (phono jacks):
Sensitivity 800 mV,
impedance 47 kilohms
Outputs
PHONES (stereo minijack):
Accepts headphones with
an impedance of 8 ohms or
more
SPEAKER: Accepts impedance of 6 to
16 ohms.
— Continued on next page —
