Sony SS-DP1000D User Manual

HCD-DP1000D
2222
6-1. CIRCUIT BOARD LOCATION
DRIVER board
LEAF SW board
CD-PANEL board
TRANS board
SUB TRANS board
DSP board
MB board
VIDEO board
MAIN board
SURROUND AMP boar
d
FRONT AMP board
OPT IN board
PANEL board
HEAD (B) board
HEAD (A) board
RF-240 board
MOTOR board
SENSOR board
DIODE board
IC701 4 INB
IC701 7 INC
IC701 9 OUT C2
IC701 qs OUT B2
IC701 2 INA
IC102 3 27-1OUT
r
WAVEFORMS
1
IC102 8 XTO
2
3
IC102 9 512-2OUT
4.0Vp-p
27MHz
DVD STOP : 22.5792MHz
DVD PLAY : 24.576MHx
3.2Vp-p
IC102 qd 33-2OUT
3.2Vp-p
33.8688MHz
4
4.0Vp-p
27MHz
IC103 ed X1
5
3.0Vp-p
16.5MHz
6
7
8
9
0
1.3Vp-p
H
1.0Vp-p
H
1.3 Vp-p
H
2.6Vp-p
H
2.0Vp-p
H
– MB BOARD –
0.72Vp-p
0.2V/div
100nsec/div
0.5Vp-p
1.4Vp-p
0.5V/div
100nsec/div
0.5V/div
1msec/div
0.1V/div
1msec/div
0.3Vp-p
– PF-240 BOARD –
IC001 2 RFIN
1
IC001 ra TE
2
IC001 rs FE
3
IC001 tl SIGO
4
– PANEL BOARD –
IC1101 is XO
1
3.0Vp-
p
4MHz
3.8Vp-p
4.5MHz
3.0Vp-p
16MHz
35Vp-p
80kHz
122Vp-p
80kHz
3.2Vp-p
32.768kHz
IC51 ws XOUT
5
IC401 qa XC-OUT
3
IC401 qd X-OUT
4
NO303 8 E-HOT
1
T301 4
2
– MAIN BOARD –
IC701 qg OUT A1
1.3Vp-p
H
qa
