60
HCD-DP1000D
Description
Pin NamePin No. I/O
58 MOD0 I Operation mode signal input (Not used)
59 EXLOCK I Lock signal input
60 VDDI I Power supply
61 VSS — Ground
62, 63 A17, A16 O External memory address output (SRAM) (Not used)
64 to 66 A15 - A13 O External memory address output (SRAM)
67 GP10 I/O LRCK0
68 GP9 (DECODE) O DECODE
69 GP8 (AUDIO) I AUDIO
70 VDDI I Power supply
71 VSS — Ground
72 to 75 D15 - D12 I/O External memory data input /output (general port)
76 VDDE I Power supply
77 to 80 D11 - D8 I/O External memory data input /output (general port)
81 VSS — Ground
82 to 85 A9 - A12 O External memory address output (SRAM)
86 TDO O Simple emulation data output (Not used)
87 TMS I Simple emulation data input start, end terminal (Not used)
88 XTRST I Simple emulation async BREAK signal input terminal (Not used)
89 TCK I Simple emulation clock signal input (Not used)
90 TDI I Simple emulation data input (Not used)
91 VSS — Ground
92 to 97 A8 - A3 O External memory address output (SRAM)
98, 99 D7, D6 I/O External memory data input/output (SRAM)
100 VDDI I Power supply
101 VSS — Ground
102 to 105 D5 - D2 I/O External memory data input/output (SRAM)
106 VDDE I Power supply
107, 108 D1, D0 I/O External memory data input/output (SRAM)
109, 110 A2, A1 O External memory address output (SRAM)
111 VSS — Ground
112 A0 O External memory address output (SRAM)
113 PM I PLL initialization input terminal
114, 115 SDI3, SDI4 I Audio IF data input (Not used)
116 SYNC I Sync/async selection input (L : sync, H : async)
117 to 119 VSS — Ground
120 VDDI I Power supply
