9
HCD-DV2D
Note: Follow the disassembly procedure in the numerical order given.
3-2. COVER TOP, DC FAN
2 two s crews
(+BTP 3
× 8)
7 s crew
(+BVTP 3
× 8)
9 four s crews
(+BVTP 3
× 8)
6 two s crews
(+BVTP 3
× 8
)
8 connector
(3P)(CN350)
4
q; DC fan
qa cover HT-SINK
b
5 cover top
1 two s crews
(+BTP 3
× 8)
3 five s crews
(+BTP 3
× 8)
a
a
b
1 two s crews
(+BVTP 3
× 10)
qh two s crews
(+BVTP 3
× 10)
q; s crew
(+BTP 3
× 8)
9 three s crews
(+BVTP 3
× 10)
8 two s crews
(+BVTP 3
× 8)
qd two s crews
(+BVTP 3
× 8)
2 two s crews
(+BVTP 3
× 10)
7 AMP board
3 connector
(10P) (CN108)
4 connector
(7P) (CN102)
5 connector
(3P) (CN106)
6 connector
(5P) (CN101)
qs wire (flat type)
(5core) (CN851)
qf wire (flat type)
(11core)
qa earth wire
qj AV board
qg tuner
ql panel back
qk two claws
3-3. AMP BOARD, AV BOARD, TUNER (FM/AM)
