HCD-DV2D
3-5. DVD MECH COVER A/B
3-4. MPEG BOARD
1 three s crews
(+BTP 3
× 8)
8 MPEG board
3 wire (flat type)
(6core) (J706)
2 connector
(5P) (J707
)
5 wire (flat type)
(9core) (J701)
7 wire (flat type)
(5core) (J703)
4 wire (flat type)
(24core) (J705)
6 connector
(9P) (J702)
3 two s crews
(+BTP 3
× 8)
5 DVD mech cover A
7 DVD mech cover B
4 two hooks
1 s crew
(+BTP 3
× 8)
2 earth wire
6 two s crews
(+BVTP 3
× 8)
