HCD-RG60
AEP Model
UK Model
SERVICE MANUAL
MINI HI-FI COMPONENT SYSTEM
Ver 1.0 2001.07
Sony Corporation
Home Audio Company
Shinagawa Tec Service Manual Production Group
9-873-193-01
2001G0200-1
© 2001.7
• HCD-RG60 is the tuner, deck, CD
and amplifier section in MHC-
RG60.
Model Name Using Similar Mechanism HCD-DX30/RG40
CD CD Mechanism Type CDM58B-K6BD38
Section Base Unit Name BU-K6BD38
Optical Pick-up Name KSM-213DCP
Tape deck
Model Name Using Similar Mechanism HCD-DX30/RG40
Section
— Continued on next page —
SPECIFICATIONS
Amplifier section
DIN power output (rated) 80 + 80 watts
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
100 + 100 watts (6 ohms
at 1 kHz, 10% THD)
Music power output (reference)
180 + 180 watts (6 ohms
at 1 kHz, 10% THD)
Inputs
MD/VIDEO (AUDIO) IN (phono jacks):
voltage 450/250 mV,
impedance 47 kilohms
GAME (AUDIO) IN (phono jack):
voltage 450 mV,
impedance 47 kilohms
MIC (mini jack): sensitivity 1 mV,
impedance 10 kilohms
Outputs
PHONES (stereo mini jack):
accepts headphones of
8 ohms or more
FRONT SPEAKER: accepts impedance of 6 to
16 ohms
SURROUND SPEAKER
accepts impedance of 6 to
16 ohms
CD player section
System Compact disc and digital
audio system
Laser Semiconductor laser
(λ =780 nm)
Emission duration:
continuous
Laser output Max. 44.6 µW*
*This output is the value
measured at a distance of
200 mm from the
objective lens surface on
the Optical Pick-up Block
with 7 mm aperture.
Frequency response 2 Hz – 20 kHz (±0.5 dB)
Wavelength 780 – 790 nm
Signal-to-noise ratio More than 90 dB
Dynamic range More than 90 dB
CD OPTICAL DIGITAL OUT
(Square optical connector jack, rear panel)
Wavelength 660 nm
Output Level –18 dBm
