SECTION 1
SERVICING NOTES
UNLEADED SOLDER
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
• Unleaded solder melts at a temperature about 40 °C higher
than ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350 °C.
Caution: The printed pattern (copper foil) may peel away if
the heated tip is applied for too long, so be careful!
• Strong viscosity
Unleaded solder is more viscous (sticky, less prone to fl ow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.
• Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
ADVANCE PREPARATION WHEN CONFIRMING OP-
ERATION
All the units included in the HT-RT3 (SA-WRT3, SS-RT3/SRT3,
remote control) are required to confi rm the operation of SA-WRT3.
Check in advance that you have all the units.
NOTE OF PERFORMING THE OPERATION CHECK IN
THE STATE THAT HEAT SINK WAS REMOVED
When performing the operation check in the state that this unit was
disassembled, it is possible to perform the operation check in the
state that heat sink was removed. But don’t perform the operation
check in the long time, and perform the operation check in the
volume state as low as possible.
IF “PRTCT” APPEARS IN THE FRONT PANEL DIS-
PLAY OF THE SUBWOOFER
t Press 1 to turn off the system. After
the display turns off , disconnect the
AC power cord (mains lead) then
check that nothing is blocking the
ventilation holes of the Subwoofer.
TABLE OF CONTENTS
1. SERVICING NOTES
............................................. 4
2. DISASSEMBLY
2-1. Disassembly Flow ........................................................... 8
2-2. Front Panel Section ......................................................... 9
2-3. Loudspeaker 16cm .......................................................... 10
2-4. Chassis Section ............................................................... 11
2-5. BLUETOOTH Module ................................................... 11
2-6. SPEAKER CHUKEI PC BOAR Board .......................... 12
2-7. MAIN Board, CONNECTOR Board,Switching
Regulator ........................................................................ 13
3. TEST MODE ............................................................ 14
4. TROUBLESHOOTING ........................................... 15
5. DIAGRAMS
5-1. Block Diagram - MAIN CONTROL Section - ............... 19
5-2. Block Diagram - AUDIO Section - ................................. 20
5-3. Block Diagram - POWER SUPPLY Section - ................ 21
5-4. Printed Wiring Board - MAIN Board
(US, CND, AUS, EA, SP, AR, E12, LA9/
Former type: AEP, UK) - ................................................ 23
5-5. Printed Wiring Board - MAIN Board
(New type: AEP, UK) - ................................................... 24
5-6. Printed Wiring Board - OLED CHUKEI PC
BOAR Board - ................................................................ 25
5-7. Schematic Diagram - OLED CHUKEI PC
BOAR Board - ................................................................ 25
5-8. Printed Wiring Board - TOUCH Board - ........................ 26
5-9. Schematic Diagram - TOUCH Board - ........................... 26
5-10. Printed Wiring Board - SPEAKER CHUKEI PC
BOAR Board - ................................................................ 27
5-11. Schematic Diagram - SPEAKER CHUKEI PC
BOAR Board - ................................................................ 27
5-12. Printed Wiring Board - CONNECTOR Board - ............. 28
5-13. Schematic Diagram - CONNECTOR Board - ................ 28
5-14. Printed Wiring Board - USB Board - .............................. 28
6. EXPLODED VIEWS
6-1. Overall Section ............................................................... 30
6-2. Chassis Section ............................................................... 31
6-3. MAIN Board Section ...................................................... 32
7. ELECTRICAL PARTS LIST .............................. 33
Accessories are listed in the last part of the electrical parts list.
(AEP, UK only)
Note: The MAIN board of AEP and UK has been changed in the mid-
way of production.
Refer to “CHANGE OF MAIN BOARD AND INSTRUCTION
MANUAL” on page 5 for “Former type” and “New type”.
