ST-EX880/MS717
– 7 – – 8 –
SECTION 5
DIAGRAMS
5-1. NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS
Note on Schematic Diagram:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ω and
1
/
4
W or less unless otherwise
specified.
•
¢
: internal component.
• 2 : nonflammable resistor.
• C : panel designation.
Note on Printed Wiring Boards:
• X : parts extracted from the component side.
•
¢
: internal component.
• Indication of transistor.
Abbreviation:
HK : Hong Kong
JE : Tourist
MY : Malaysia
SP : Singapore
• U : B+ Line.
• V : B– Line.
• H : adjustment for repair.
• Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
no mark : FM
( ) : AM (MW)
〈〈 〉〉 : STAND BY
[ ] : MUTING ON
• Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
• Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
• Circled numbers refer to waveforms.
• Signal path.
F : FM
f : AM (MW)
Note: The components identified by mark ! or dotted line
with mark ! are critical for safety.
Replace only with part number specified.
B
These are omitted.
CE
Q
• Circuit Boards Location
• Waveforms
– MAIN Section –
