Sony ST-S5 - General; Location of Controls

4
ST-S5
1 ANTENNA terminal
2 SYSTEM CONTROL 1 connector (TO TA-S7AV)
3 SYSTEM CONTROL 2 connector (TO TA-S7AV)
4 SYSTEM CONTROL 3 connector (FROM CDP-S3)
5 OPTICAL IN terminal
6 OPTICAL IN terminal (FROM CDP-S3)
7 SYSTEM CONTROL 4 connector (TO TC-S3)
8 OPTICAL OUT terminal
9 SUB WOOFER OUT jack
0 MD IN/OUT jack
qa VIDEO (AUDIO) IN jack
– Rear Panel –
SECTION 2
GENERAL
This section is extracted from
instruction manual.
LOCATION OF CONTROLS
– Front Panel –
–
–
+
+
qh qj
qk
ql
w;
wawswdwfwgwh
CLOCK/TIMER wg (13, 21, 29)
DISPLAY qh (13, 16, 18, 29, 35)
ENTER w; (17, 18)
IR receptor wh
PRESET +/– ws (17, 18)
PTY (AEP, UK models only)
wa
(18)
STEREO/MONO qj (17)
TIMER SELECT wf (22, 30)
TUNER/BAND wd (17)
TUNER MEMORY qk (17)
TUNING +/– ql
(17)
1
2
3
4 5 6 7
8
0
9
qa
