Sony ST-SE370 - Disassembly Instructions; Disassembly Flow Chart; Case Disassembly

ST-SE370
4
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
SECTION 2
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
2-2. CASE (407026)
2-2. CASE (407026)
(Page 4)
2-3. MAIN BOARD
(Page 5)
SET
1 two screws
(case 3 TP2)
2 two screws
(case 3 TP2
)
3 three screws
(case 3 TP2)
4 case (407026)
