Sony ST-SE370 - Main Board Disassembly

ST-SE370
5
2-3. MAIN BOARD
5 MAIN board
2 connector (CNP701)
2 connector (CNP702)
2 connector (CNP951)
2 connector (CNP901)
1 wire (flat type) (15 core)
(CN101)
3 screw
(BV/RING)
3 screw
(BVTP3
× 8 (S))
4 screw
(BVTT3
× 6 (S)
)
