Sony STR-435 - Rear Panel Descriptions

28
US
Rear Panel Descriptions
1 ANTENNA (AM and FM)
2 y ground terminal
(STR-DE535 only)
3 PHONO (STR-DE535 only)
4 CD
5 MD/TAPE
6 TV/SAT (TV/LD)
7 VIDEO
!¢ VOLTAGE SELECTOR (except
Canada, Australia, Singapore
and Malaysia)
!∞ AC power cord
!§ SWITCHED AC OUTLET
!¶ SPEAKERS FRONT (A/B)
!• IMPEDANCE SELECTOR
8 5.1 CH/DVD
9 MONITOR
!º CTRL A1 II (STR-DE535 only)
!¡ WOOFER
(STR-DE535 - 2 pins,
STR-DE435 - 1 pin)
!™ SPEAKERS REAR
!£ SPEAKERS CENTER
