4: Connecting the antennas
Connect the supplied AM loop antenna and
FM wire antenna.
Notes
• To prevent noise pickup, keep the AM loop antenna
away from the receiver and other components.
• Be sure to fully extend the FM wire antenna.
• After connecting the FM wire antenna, keep it as
horizontal as possible.
DIGITAL
VIDEO 1
IN
VIDEO 2
IN
DVD
IN
COAXIAL
OPTICAL
SA-CD / CD MD/TAPE
OUT
L
R
IN
L
R
AUDIO IN
DVD
AUDIO ININ
VIDEO 2
AUDIO IN
VIDEO 1
AUDIO OUT
L
R
L
R
AUDIO
OUT
SUB
WOOFER
FRONT A
+ –
R
L
SPEAKERS
ANTENNA
AM
FM wire antenna (supplied)
AM loop antenna (supplied)
