30
STR-DH130
SECTION 6
ELECTRICAL PARTS LIST
A-1847-546-A DISPLAY BOARD, COMPLETE
***********************
< CAPACITOR >
C100 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C101 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C106 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C107 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C110 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C111 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C112 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C114 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C115 1-126-157-11 ELECT 10uF 20% 16V
C144 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C162 1-124-261-00 ELECT 10uF 20% 50V
C163 1-116-452-91 CERAMIC CHIP 0.022uF 10% 50V
C164 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C165 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C166 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C167 1-119-772-91 ELECT 47uF 20% 35V
C168 1-165-722-11 ELECT 100uF 20% 10V
< CONNECTOR >
CNS101 1-784-776-11 CONNECTOR, FFC 15P
< DIODE >
D001 6-502-968-01 DI DZ2J062M0L
D101 6-500-848-01 DIODE MC2840-T112-1
D102 6-500-848-01 DIODE MC2840-T112-1
< FERRITE BEAD >
FB100 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB101 1-400-862-11 BEAD, FERRITE
< FLUORESCENT INDICATOR TUBE >
FL101 1-483-065-11 VACUMM FLOURESCENT DISPLAYS
< IC >
IC100 6-701-729-01 IC PT6315
IC103 6-600-768-01 IC PNA4823M03S0
< TRANSISTOR >
Q001 6-550-065-01 TRANSISTOR CPH5504-TL-E
< RESISTOR >
R101 1-216-813-11 METAL CHIP 220 5% 1/10W
R102 1-216-815-11 METAL CHIP 330 5% 1/10W
R103 1-216-817-11 METAL CHIP 470 5% 1/10W
R104 1-216-819-11 METAL CHIP 680 5% 1/10W
R105 1-216-821-11 METAL CHIP 1K 5% 1/10W
R106 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R108 1-216-813-11 METAL CHIP 220 5% 1/10W
R109 1-216-815-11 METAL CHIP 330 5% 1/10W
R110 1-216-817-11 METAL CHIP 470 5% 1/10W
R115 1-216-809-11 METAL CHIP 100 5% 1/10W
R116 1-216-809-11 METAL CHIP 100 5% 1/10W
R117 1-216-809-11 METAL CHIP 100 5% 1/10W
R118 1-216-844-11 METAL CHIP 82K 5% 1/10W
R119 1-216-809-11 METAL CHIP 100 5% 1/10W
R120 1-216-797-11 METAL CHIP 10 5% 1/10W
R122 1-216-839-11 METAL CHIP 33K 5% 1/10W
R124 1-216-295-91 SHORT CHIP 0
R198 1-240-915-11 RES-CHIP 1 1% 1/2W
R199 1-240-915-11 RES-CHIP 1 1% 1/2W
R200 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R201 1-216-839-11 METAL CHIP 33K 5% 1/10W
R202 1-216-809-11 METAL CHIP 100 5% 1/10W
R203 1-216-809-11 METAL CHIP 100 5% 1/10W
< VARIABLE RESISTOR >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S101 1-771-410-21 SWITCH, TACTILE (DIMMER)
S102 1-771-410-21 SWITCH, TACTILE (MUTING MODE)
S103 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S104 1-771-410-21 SWITCH, TACTILE (TREBLE +)
S105 1-771-410-21 SWITCH, TACTILE (TREBLE -)
S106 1-771-410-21 SWITCH, TACTILE (BASS +)
S107 1-771-410-21 SWITCH, TACTILE (BASS -)
S108 1-771-410-21 SWITCH, TACTILE (MEMORY/ENTER)
S109 1-771-410-21 SWITCH, TACTILE (MUTING)
S110 1-771-410-21 SWITCH, TACTILE (TUNING +)
S111 1-771-410-21 SWITCH, TACTILE (TUNING -)
< TRANSFORMER >
T001 1-445-231-11 TRANSFORMER, DC-DC CONVERTER
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
CND : Canadian model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifi é.
DISPLAY
