60
STR-K990
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< TRANSFORMER >
0 T902 1-443-516-11 POWER TRANSFORMER
************************************************************
VIDEO BOARD
************
< CAPACITOR >
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-947-11 ELECT 47uF 20% 35V
C213 1-126-947-11 ELECT 47uF 20% 35V
C214 1-127-888-11 CERAMIC 0.1uF 10% 50V
C215 1-127-888-11 CERAMIC 0.1uF 10% 50V
C220 1-126-947-11 ELECT 47uF 20% 35V
C221 1-126-947-11 ELECT 47uF 20% 35V
C223 1-135-799-11 CERAMIC 0.47uF 50V
C224 1-135-799-11 CERAMIC 0.47uF 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C309 1-126-964-11 ELECT 10uF 20% 50V
C310 1-126-964-11 ELECT 10uF 20% 50V
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-964-11 ELECT 10uF 20% 50V
C313 1-126-964-11 ELECT 10uF 20% 50V
C314 1-126-964-11 ELECT 10uF 20% 50V
C315 1-126-964-11 ELECT 10uF 20% 50V
C316 1-126-964-11 ELECT 10uF 20% 50V
C330 1-127-888-11 CERAMIC 0.1uF 10% 50V
C331 1-127-888-11 CERAMIC 0.1uF 10% 50V
C337 1-126-947-11 ELECT 47uF 20% 35V
C338 1-126-947-11 ELECT 47uF 20% 35V
C341 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CNP202 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
* CNP203 1-564-507-11 PLUG, CONNECTOR 4P
CNS207 1-784-774-11 CONNECTOR, FFC 13P
< DIODE >
D203 8-719-991-33 DIODE 1SS133T-77
D204 8-719-991-33 DIODE 1SS133T-77
< IC >
IC203 6-701-890-01 IC NJM2595D
IC304 6-707-363-01 IC NJM2586AL
0 IC804 8-759-245-79 IC TA79005S
0 IC807 8-759-231-53 IC TA7805S
< JACK >
J200 1-794-978-11 JACK, PIN 3P (DVD,VIDEO 1,SAT)
J201 1-815-043-11 JACK, PIN 2P (VIDEO 1,MONITOR)
J301 1-816-592-11 JACK, PIN 9P (COMPONENT VIDEO)
J302 1-815-360-11 JACK, PIN 3P (MONITOR OUT)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R219 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
R301 1-247-804-11 CARBON 75 5% 1/4W
R302 1-247-804-11 CARBON 75 5% 1/4W
R303 1-247-804-11 CARBON 75 5% 1/4W
R304 1-247-804-11 CARBON 75 5% 1/4W
R305 1-247-804-11 CARBON 75 5% 1/4W
R306 1-247-804-11 CARBON 75 5% 1/4W
R307 1-247-804-11 CARBON 75 5% 1/4W
R308 1-247-804-11 CARBON 75 5% 1/4W
R309 1-247-804-11 CARBON 75 5% 1/4W
R310 1-247-804-11 CARBON 75 5% 1/4W
R311 1-247-804-11 CARBON 75 5% 1/4W
R312 1-247-804-11 CARBON 75 5% 1/4W
************************************************************
VIDEO3 BOARD
*************
< CAPACITOR >
C293 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C294 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C298 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C299 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN201 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
* CN202 1-690-880-31 LEAD (WITH CONNECTOR)
< JACK >
J298 1-819-187-11 PIN JACK 3P (VIDEO3 IN / PORTABLE AV IN)
< RESISTOR >
R298 1-216-821-11 METAL CHIP 1K 5% 1/10W
R299 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
MISCELLANEOUS
**************
8 1-829-994-11 WIRE (FLAT TYPE) (17 CORE)
0 57 1-783-820-11 CORD, POWER
59 1-828-973-11 WIRE (FLAT TYPE) (13 CORE)
60 1-828-953-11 WIRE (FLAT TYPE) (9 CORE)
0 F4001 1-532-465-33 FUSE (T3.15AL/250V)
0 F4002 1-532-465-33 FUSE (T3.15AL/250V)
0 F901 1-533-453-12 FUSE, GLASS TUBE (DIA. 5) (5A/125V)
0 Q503 6-702-390-01 IC MN2488-OPY-MK
0 Q504 6-702-391-01 IC MP1620-OPY-MK
0 Q603 6-702-390-01 IC MN2488-OPY-MK
0 Q604 6-702-391-01 IC MP1620-OPY-MK
0 Q653 6-702-390-01 IC MN2488-OPY-MK
0 Q654 6-702-391-01 IC MP1620-OPY-MK
0 Q703 6-702-390-01 IC MN2488-OPY-MK
VIDEO VIDEO3STANDBY
