Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 43 —
R614 1-249-409-11 CARBON 220 5% 1/4W F
R615 1-249-409-11 CARBON 220 5% 1/4W F
R616 1-247-843-11 CARBON 3.3K 5% 1/4W
R617 1-247-843-11 CARBON 3.3K 5% 1/4W
R618 1-247-843-11 CARBON 3.3K 5% 1/4W
R619 1-249-429-11 CARBON 10K 5% 1/4W
R620 1-249-429-11 CARBON 10K 5% 1/4W
R621 1-249-429-11 CARBON 10K 5% 1/4W
R622 1-249-429-11 CARBON 10K 5% 1/4W
R623 1-249-429-11 CARBON 10K 5% 1/4W
R624 1-249-429-11 CARBON 10K 5% 1/4W
R630 1-249-435-11 CARBON 33K 5% 1/4W
R631 1-249-435-11 CARBON 33K 5% 1/4W
R632 1-249-437-11 CARBON 47K 5% 1/4W
R633 1-247-903-00 CARBON 1M 5% 1/4W
R634 1-249-437-11 CARBON 47K 5% 1/4W
R635 1-247-903-00 CARBON 1M 5% 1/4W
R636 1-249-435-11 CARBON 33K 5% 1/4W
R637 1-249-429-11 CARBON 10K 5% 1/4W
R638 1-249-437-11 CARBON 47K 5% 1/4W
R639 1-249-437-11 CARBON 47K 5% 1/4W
R640 1-247-903-00 CARBON 1M 5% 1/4W
R641 1-247-903-00 CARBON 1M 5% 1/4W
R642 1-247-843-11 CARBON 3.3K 5% 1/4W
(AEP,UK)
R642 1-249-410-11 CARBON 270 5% 1/4W F
(E3,EA3,SP,MY,HK,TW,IA)
R642 1-249-425-11 CARBON 4.7K 5% 1/4W F
(EE,CIS)
R642 1-249-414-11 CARBON 560 5% 1/4W F
(JE)
R642 1-249-427-11 CARBON 6.8K 5% 1/4W F
(CND)
R643 1-249-427-11 CARBON 6.8K 5% 1/4W F
R662 1-247-903-00 CARBON 1M 5% 1/4W
R663 1-247-903-00 CARBON 1M 5% 1/4W
R664 1-247-903-00 CARBON 1M 5% 1/4W
R665 1-247-903-00 CARBON 1M 5% 1/4W
R666 1-249-417-11 CARBON 1K 5% 1/4W F
< SWITCH >
S501 1-762-751-11 SWITCH, TACTILE (MOVIE)
S503 1-762-751-11 SWITCH, TACTILE (EFFECT ON/OFF)
S504 1-762-751-11 SWITCH, TACTILE (LOW FREQ)
S505 1-762-751-11 SWITCH, TACTILE (MEMORY)
S506 1-762-751-11 SWITCH, TACTILE (TUNING MODE)
S507 1-762-751-11 SWITCH, TACTILE (FLASH)
S508 1-762-751-11 SWITCH, TACTILE (POWER)
S509 1-762-751-11 SWITCH, TACTILE (RDS)(AEP,UK)
S512 1-762-751-11 SWITCH, TACTILE (GAME)
S513 1-762-751-11 SWITCH, TACTILE (P FILE)
S514 1-762-751-11 SWITCH, TACTILE (MEMO)
S515 1-762-751-11 SWITCH, TACTILE (HIGH FREQ)
S516 1-762-751-11 SWITCH, TACTILE (REPEAT)
S517 1-762-751-11 SWITCH, TACTILE (1/ALL DISCS)
S518 1-762-751-11 SWITCH, TACTILE (PLAY MODE)
S519 1-762-751-11 SWITCH, TACTILE (EDIT)
S520 1-762-751-11 SWITCH, TACTILE (DBFB)
S521 1-762-751-11 SWITCH, TACTILE (GROOVE)
S522 1-762-751-11 SWITCH, TACTILE (FUNCTION)
S523 1-762-751-11 SWITCH, TACTILE (MONO/ST)
S524 1-762-751-11 SWITCH, TACTILE (TUNER BAND)
S525 1-762-751-11 SWITCH, TACTILE (TIMER SELECT)
S526 1-762-751-11 SWITCH, TACTILE (CLOCK TIMER SET)
S531 1-762-751-11 SWITCH, TACTILE (KARAOKE PON/MPX)
S532 1-762-751-11 SWITCH, TACTILE (SURROUND)
S533 1-762-751-11 SWITCH, TACTILE (LOOP)
S535 1-467-869-11 ENCODER, ROTARY (VOLUME)
S537 1-762-751-11 SWITCH, TACTILE (WAVE)
S538 1-762-751-11 SWITCH, TACTILE (DISPLAY)
< VIBRATOR >
X501 1-579-125-11 VIBRATOR, CERAMIC 5MHz
X502 1-567-098-41 VIBRATOR, CRYSTAL 32KHz
************************************************************
* 1-666-065-11 PRI BOARD
*********
1-533-399-31 HOLDER, FUSE
< CONNECTOR >
CN851 1-564-321-00 PIN, CONNECTOR 2P
< FUSE >
! F851 1-532-465-51 FUSE, TIME LAG 3.15A 250V
(EXCEPT CND)
! F852 1-576-193-21 FUSE, TIME LAG 6.3A 125V (CND)
! F852 1-532-506-51 FUSE, TIME LAG 6.3A 250V
(E,EA3,SP,MY,HK,TW,IA,AR,JE)
<RESISTOR >
! R852 1-202-725-00 SOLID 3.3M 10% 1/2W
(CND)
< SWITCH >
! VS851 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(E,EA3,SP,MY,HK,TW,IA,AR,JE)
************************************************************
* 1-666-059-11 SEC BOARD
**********
1-533-399-11 HOLDER, FUSE
< CONNECTOR >
* CN852 1-564-527-11 PLUG, CONNECTOR 12P
< FUSE >
! F857 1-532-749-11 FUSE, GLASS TUBE 8A 125V (CND)
! F857 1-532-506-51 FUSE, TIME LAG 6.3A 250V
(EXCEPT CND)
! F858 1-532-749-11 FUSE, GLASS TUBE 8A 125V (CND)
! F858 1-532-506-51 FUSE, TIME LAG 6.3A 250V
(EXCEPT CND)
PANEL VOLUME SECPRI
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
