Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 47 —
< VARIABLE RESISTOR >
RV41 1-238-601-11 ADJ, CARBON 22K
RV42 1-238-600-11 ADJ, CARBON 10K
RV1701 1-238-600-11 ADJ, CARBON 10K (EE,CIS)
RV1702 1-238-599-11 ADJ, CARBON 4.7K (EE,CIS)
< TERMINAL >
TM1 1-537-488-11 TERMINAL BOARD (ANT) (ANTENNA)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz)
X41 1-760-220-11 FILTER, CERAMIC (10.7MHz)
X42 1-527-981-00 FILTER, CERAMIC (450kHz)
X43 1-577-075-11 OSCILLATOR, CERAMIC (456kHz)
X1751 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz) (AEP,UK)
*************************************************************
MISCELLANEOUS
*************
6 1-233-544-21 ENCAPSULATED COMPONENT(CND)
6 1-233-545-21 ENCAPSULATED COMPONENT
(E2,EA4,TH,AR,AUS)
6 1-233-546-21 ENCAPSULATED COMPONENT
(E3,EA3,MY,SP,HK,TW,IA)
6 1-693-385-21 TUNER (JE)
7 1-666-067-11 DUMMY BOARD
! 12 1-690-608-11 CORD, POWER (AUS)
! 12 1-751-326-31 CORD, POWER (TH)
! 12 1-777-070-21 CORD, POWER (CND)
! 12 1-777-071-21 CORD, POWER
(AEP,EE,CIS,EA3,EA4,MY,SP,HK,TW,AR)
! 12 1-777-513-11 CORD, POWER (UK)
! 12 1-782-315-11 CORD, POWER (E,IA,JE)
! 13 1-569-007-11 ADAPTOR, CONVERSION 2P (E,EA4,IA,JE)
! 13 1-569-008-21 ADAPTOR, CONVERSION 2P
(EA3,MY,SP,TW,AR)
! 13 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
! F851 1-532-465-51 FUSE, TIME LAG 3.15A 250V
(EXCEPT CND)
! F852 1-576-193-21 FUSE, TIME LAG 6.3A 125V (CND)
! F852 1-532-506-51 FUSE, TIME LAG 6.3A 250V
(EA3,SP,MY,HK,TW,IA,AR,JE)
! F857 1-532-749-11 FUSE, GLASS TUBE 8A 125V (CND)
! F857 1-532-506-51 FUSE, TIME LAG 6.3A 250V
(EXCEPT CND,IA,JE)
! F858 1-532-749-11FUSE, GLASS TUBE 8A 125V (CND)
! F858 1-532-506-51 FUSE, TIME LAG 6.3A 250V
(EXCEPT CND,IA,JE)
! T901 1-431-364-11 TRANSFORMER, POWER (CND)
! T901 1-431-365-11 TRANSFORMER, POWER
(E,EA3,EA4,MY,SP,HK,TW,IA,TH,AR,AUS,JE)
! T901 1-431-366-11 TRANSFORMER, POWER (AEP,UK,EE,CIS)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-872-09 SCREW +BVTT 3X8 (S)
#2 7-685-881-09 SCREW +BVTT 4X8 (S)
#3 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#4 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#5 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
TCB
