COVER
FRONT PANEL SECTION
Note: Follow the disassembly procedure in the numerical order given.
SECTION 2
DISASSEMBLY
1 two screws
(case3 TP2)
2 two screws
(BVTP3 × 10
)
2 four screws
(BVTP3 × 10)
1 two screws
(case3 TP2)
3 cover
4 front panel section
1 wire (flat type) (15 core
)
(CN111)
3 claw
2 three screws
(BVTP3 × 8)
