Sony TA-FE200 - Diodes, ICs, Jacks, Coils, and Transistors

– 17 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< DIODE >
D301 8-719-987-63 DIODE 1N4148M
D302 8-719-987-63 DIODE 1N4148M
D351 8-719-987-63 DIODE 1N4148M
D352 8-719-987-63 DIODE 1N4148M
D601 8-719-987-63 DIODE 1N4148M
D902 8-719-001-15 DIODE UZL-9M2
D903 8-719-001-15 DIODE UZL-9M2
D909 8-719-987-63 DIODE 1N4148M
< IC >
IC101 8-759-184-02 IC NJM2068L-D
IC102 8-759-000-49 IC MC14066BCP
IC103 8-759-802-52 IC LC7818
IC301 8-749-941-52 IC STK-4152II
IC601 8-759-111-68 IC uPC1237HA
< JACK >
J101 1-774-411-11 JACK, PIN 6P (PHONO,TUNER,CD)
J102 1-695-188-31 JACK, PIN 4P (TAPE2/MD)
J103 1-695-188-31 JACK, PIN 4P (TAPE1/DAT)
< COIL >
L301 1-420-872-00 COIL, AIR-CORE
L351 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q101 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q151 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q301 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q351 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q701 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q702 8-729-900-36 TRANSISTOR DTC124ES
Q703 8-729-900-63 TRANSISTOR DTA124ES
Q704 8-729-900-36 TRANSISTOR DTC124ES
Q705 8-729-900-63 TRANSISTOR DTA124ES
Q706 8-729-900-89 TRANSISTOR DTC144ES
Q707 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q901 8-729-281-54 TRANSISTOR 2SC1815-BL
Q902 8-729-201-53 TRANSISTOR 2SA1015-GR
< RESISTOR >
R101 1-247-807-31 CARBON 100 5% 1/4W
R102 1-249-417-11 CARBON 1K 5% 1/4W
R103 1-249-417-11 CARBON 1K 5% 1/4W
R104 1-249-417-11 CARBON 1K 5% 1/4W
R105 1-249-417-11 CARBON 1K 5% 1/4W
R106 1-249-417-11 CARBON 1K 5% 1/4W
R107 1-249-417-11 CARBON 1K 5% 1/4W
R108 1-249-411-11 CARBON 330 5% 1/4W
R109 1-249-437-11 CARBON 47K 5% 1/4W
R110 1-249-416-11 CARBON 820 5% 1/4W
R111 1-247-897-11 CARBON 560K 5% 1/4W
R112 1-249-437-11 CARBON 47K 5% 1/4W
R113 1-249-441-11 CARBON 100K 5% 1/4W
R114 1-249-409-11 CARBON 220 5% 1/4W
R115 1-249-427-11 CARBON 6.8K 5% 1/4W
R151 1-247-807-31 CARBON 100 5% 1/4W
R152 1-249-417-11 CARBON 1K 5% 1/4W
R153 1-249-417-11 CARBON 1K 5% 1/4W
R154 1-249-417-11 CARBON 1K 5% 1/4W
R155 1-249-417-11 CARBON 1K 5% 1/4W
R156 1-249-417-11 CARBON 1K 5% 1/4W
R157 1-249-417-11 CARBON 1K 5% 1/4W
R158 1-249-411-11 CARBON 330 5% 1/4W
R159 1-249-437-11 CARBON 47K 5% 1/4W
R160 1-249-416-11 CARBON 820 5% 1/4W
R161 1-247-897-11 CARBON 560K 5% 1/4W
R162 1-249-437-11 CARBON 47K 5% 1/4W
R163 1-249-441-11 CARBON 100K 5% 1/4W
R164 1-249-409-11 CARBON 220 5% 1/4W
R165 1-249-427-11 CARBON 6.8K 5% 1/4W
R207 1-249-425-11 CARBON 4.7K 5% 1/4W
R257 1-249-425-11 CARBON 4.7K 5% 1/4W
R301 1-249-439-11 CARBON 68K 5% 1/4W
R302 1-249-417-11 CARBON 1K 5% 1/4W
R303 1-249-415-11 CARBON 680 5% 1/4W
R304 1-249-439-11 CARBON 68K 5% 1/4W
R305 1-249-421-11 CARBON 2.2K 5% 1/4W
R306 1-260-103-11 CARBON 2.2K 5% 1/2W
R307 1-249-405-11 CARBON 100 5% 1/4W
R308 1-260-099-11 CARBON 1K 5% 1/2W
R309 1-260-099-11 CARBON 1K 5% 1/2W
R310 1-249-405-11 CARBON 100 5% 1/4W
R312 1-249-419-11 CARBON 1.5K 5% 1/4W
R313 1-249-431-11 CARBON 15K 5% 1/4W
! R314 1-217-151-00 METAL PLATE 0.22 10% 2W F
R315 1-249-437-11 CARBON 47K 5% 1/4W
R316 1-247-727-11 CARBON 10 5% 1/2W
R318 1-249-393-11 CARBON 10 5% 1/4W
R320 1-249-393-11 CARBON 10 5% 1/4W
R321 1-249-393-11 CARBON 10 5% 1/4W
R351 1-249-439-11 CARBON 68K 5% 1/4W
R352 1-249-417-11 CARBON 1K 5% 1/4W
R353 1-249-415-11 CARBON 680 5% 1/4W
R354 1-249-439-11 CARBON 68K 5% 1/4W
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
MAIN
