– 18 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
TA-FE200
R355 1-249-421-11 CARBON 2.2K 5% 1/4W
R356 1-260-103-11 CARBON 2.2K 5% 1/2W
R362 1-249-419-11 CARBON 1.5K 5% 1/4W
R363 1-249-431-11 CARBON 15K 5% 1/4W
! R364 1-217-151-00
METAL PLATE
0.22 10% 2W F
R365 1-249-439-11 CARBON 68K 5% 1/4W
R366 1-247-727-11 CARBON 10 5% 1/2W
R368 1-249-393-11 CARBON 10 5% 1/4W
R601 1-247-745-11 CARBON 330 5% 1/2W
R602 1-247-745-11 CARBON 330 5% 1/2W
R603 1-249-417-11 CARBON 1K 5% 1/4W
R604 1-249-441-11 CARBON 100K 5% 1/4W
R605 1-249-437-11 CARBON 47K 5% 1/4W
R606 1-249-429-11 CARBON 10K 5% 1/4W
R701 1-247-903-00 CARBON 1M 5% 1/4W
R702 1-249-437-11 CARBON 47K 5% 1/4W
R703 1-249-433-11 CARBON 22K 5% 1/4W
R704 1-249-433-11 CARBON 22K 5% 1/4W
R705 1-249-433-11 CARBON 22K 5% 1/4W
R706 1-249-437-11 CARBON 47K 5% 1/4W
R707 1-249-433-11 CARBON 22K 5% 1/4W
R708 1-249-433-11 CARBON 22K 5% 1/4W
R709 1-249-435-11 CARBON 33K 5% 1/4W
R710 1-249-433-11 CARBON 22K 5% 1/4W
R711 1-249-433-11 CARBON 22K 5% 1/4W
R712 1-249-433-11 CARBON 22K 5% 1/4W
R902 1-247-750-11 CARBON 680 5% 1/2W
R903 1-247-750-11 CARBON 680 5% 1/2W
R904 1-247-750-11 CARBON 680 5% 1/2W
R905 1-247-750-11 CARBON 680 5% 1/2W
R907 1-247-752-11 CARBON 1K 5% 1/2W
R908 1-247-752-11 CARBON 1K 5% 1/2W
R910 1-249-429-11 CARBON 10K 5% 1/4W
R912 1-249-429-11 CARBON 10K 5% 1/4W
R913 1-249-433-11 CARBON 22K 5% 1/4W
< RELAY >
RY601 1-515-920-11 RELAY (24V)
< TERMINAL >
TM301 1-537-238-11 TERMINAL BOARD (SPEAKERS)
************************************************************
MISCELLANEOUS
**************
14 1-773-154-11 WIRE (FLAT TYPE)(21 CORE)
! CP1 1-575-651-21 CORD, POWER (AEP, German)
! CP1 1-696-586-11 CORD, POWER (UK)
! T1 1-429-447-11 TRANSFORMER, POWER
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-01 SCREW +BVTP 3X8 TYPE1
#2 7-682-548-04 SCREW +BVTT 3X8 (S)
#3 7-682-560-04 SCREW +BVTT 4X6 (S)
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
3-856-216-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
SPANISH, PORTUGUESE)(AEP, UK)
3-856-216-21 MANUAL, INSTRUCTION (GERMAN, DUTCH,
SWEDISH, ITALIAN)(AEP)
3-856-216-31 MANUAL, INSTRUCTION (GERMAN)(German)
* 4-981-575-01 CUSHION
* 4-981-581-01 INDIVIDUAL CARTON
Sony Corporation
Home A&V Products Company
9-960-697-11
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
MAIN
English
96E057552-1
Printed in Germany
© 1996. 5
Published by Quality Engineering Dept.
(Shibaura)
