TA-FE710R/FE910R
VOL
Ref. No. Part No. Description Remark
* 1-660-559-11 VOL BOARD
**********
< CAPACITOR >
C904 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
CN201 1-691-766-11 PLUG (MICRO CONNECTOR) 8P
CNJ900 1-568-317-11 SOCKET, CONNECTOR 6P
CNJ901 1-568-319-11 SOCKET, CONNECTOR 8P
< VARIABLE RESISTOR >
RV203 1-225-227-11 RES, VAR, CARBON 120K/120K (VOLUME)
************************************************************
MISCELLANEOUS
***************
! 56 1-777-185-11 CORD, POWER
! CNJ801 1-526-794-11 OUTLET, AC (AC OUTLET)
! CNJ802 1-526-794-11 OUTLET, AC (AC OUTLET)
! CNJ803 1-526-794-11 OUTLET, AC (AC OUTLET)
! F801 1-532-464-51 FUSE, TIME LAG (T2.5AL/250V) (FE710R)
! F801 1-532-465-51 FUSE, TIME LAG (T3.15AL/250V) (FE910R)
! F802 1-532-464-51 FUSE, TIME LAG (T2.5AL/250V)
Q403 8-729-232-45 TRANSISTOR 2SK1529-Y
Q404 8-729-232-46 TRANSISTOR 2SJ200-Y
Q406B 8-729-209-15 TRANSISTOR 2SD2012
Q453 8-729-232-45 TRANSISTOR 2SK1529-Y
Q454 8-729-232-46 TRANSISTOR 2SJ200-Y
! S1 1-554-920-11 SWITCH, PUSH (AC POWER) (1 KEY) (POWER)
! T1 1-431-275-11 TRANSFORMER, POWER (FE910R)
! T1 1-431-276-11 TRANSFORMER, POWER (FE710R)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-473-656-11 REMOTE COMMANDER (RM-S316)
3-860-499-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH,
SPANISH,PORTUGUESE)
3-860-499-21 MANUAL, INSTRUCTION (GERMAN,DUTCH,
SWEDISH,ITALIAN)
4-981-643-01 COVER, BATTERY (FOR RM-S316)
The components identified by mark
! or dotted line with mark. ! are
critical for safety.
Replace only with part number
specified.
