– 21 –
INPUTHPEON
SECTION 3
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by mark
! or dotted line with mark. ! are
critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-660-560-11 EON BOARD
**********
< CONNECTOR >
CN952 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< DIODE >
D901 8-719-313-50 LED SEL6810A-TH12 (EON LINK)
< RESISTOR >
R901 1-249-393-11 CARBON 10 5% 1/4W
< SWITCH >
S902 1-571-112-21 SWITCH, PUSH (1 KEY) (EON LINK)
************************************************************
* 1-662-375-11 HP BOARD
*********
< CONNECTOR >
CN961 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< JACK >
J701 1-750-735-11 JACK (LARGE TYPE) (PHONES)
************************************************************
* 1-660-557-11 INPUT BOARD
************
< CAPACITOR >
C101 1-162-286-31 CERAMIC 220PF 10% 50V
C102 1-162-286-31 CERAMIC 220PF 10% 50V
C103 1-162-286-31 CERAMIC 220PF 10% 50V
C104 1-162-286-31 CERAMIC 220PF 10% 50V
C105 1-162-286-31 CERAMIC 220PF 10% 50V
C106 1-162-286-31 CERAMIC 220PF 10% 50V
C107 1-162-286-31 CERAMIC 220PF 10% 50V
C151 1-162-286-31 CERAMIC 220PF 10% 50V
C152 1-162-286-31 CERAMIC 220PF 10% 50V
C153 1-162-286-31 CERAMIC 220PF 10% 50V
C154 1-162-286-31 CERAMIC 220PF 10% 50V
C155 1-162-286-31 CERAMIC 220PF 10% 50V
C156 1-162-286-31 CERAMIC 220PF 10% 50V
C157 1-162-286-31 CERAMIC 220PF 10% 50V
C907 1-126-963-11 ELECT 4.7uF 20% 50V
C908 1-126-963-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
CN200 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN904 1-691-773-11 PLUG (MICRO CONNECTOR) 11P
< DIODE >
D101 8-719-987-63 DIODE 1N4148M
D102 8-719-987-63 DIODE 1N4148M
D103 8-719-987-63 DIODE 1N4148M
D104 8-719-987-63 DIODE 1N4148M
D105 8-719-987-63 DIODE 1N4148M
D106 8-719-987-63 DIODE 1N4148M
D107 8-719-987-63 DIODE 1N4148M
D108 8-719-987-63 DIODE 1N4148M
D917 8-719-001-76 DIODE UZL-12M3
< JACK >
* J101 1-573-142-11 JACK, PIN 4P (TUNER,PHONO (INPUT))
* J102 1-573-142-21 JACK, PIN 4P (AUX,CD (INPUT))
* J103 1-573-142-21 JACK, PIN 4P (TAPE1/DAT)
* J104 1-573-142-21 JACK, PIN 4P (TAPE2/MD)
< TRANSISTOR >
Q101 8-729-900-80 TRANSISTOR DTC114ES
Q102 8-729-900-80 TRANSISTOR DTC114ES
Q103 8-729-900-80 TRANSISTOR DTC114ES
Q104 8-729-900-80 TRANSISTOR DTC114ES
Q105 8-729-900-80 TRANSISTOR DTC114ES
Q106 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R101 1-249-995-11 CARBON 1M 5% 1/4W
R102 1-249-995-11 CARBON 1M 5% 1/4W
R103 1-249-995-11 CARBON 1M 5% 1/4W
R104 1-249-923-11 CARBON 1K 5% 1/4W
R105 1-249-995-11 CARBON 1M 5% 1/4W
R106 1-249-923-11 CARBON 1K 5% 1/4W
R107 1-249-995-11 CARBON 1M 5% 1/4W
R110 1-249-995-11 CARBON 1M 5% 1/4W
R111 1-249-995-11 CARBON 1M 5% 1/4W
R151 1-249-995-11 CARBON 1M 5% 1/4W
R152 1-249-995-11 CARBON 1M 5% 1/4W
R153 1-249-995-11 CARBON 1M 5% 1/4W
R154 1-249-923-11 CARBON 1K 5% 1/4W
R155 1-249-995-11 CARBON 1M 5% 1/4W
