Five menu languages
You can select the menu language from among five
languages on the menu.
EIA standard 19-inch rack mounting
By using an MB-502B mounting bracket (not
supplied), the monitor can be mounted in an EIA
standard 19-inch rack.
For details on mounting, refer to the instruction manuals
supplied with the mounting bracket kit or slide rail kit.
SDI (Serial Digital Interface) Kit (for audio)
By using the Sony BKM-102 Component SDI Kit (for
audio, optional), you can monitor SMPTE 259M 4:2:2
serial digital audio signal from a digital VCR with the
picture.
Serial Remote Interface Kit
By using the Sony BKM-103 Serial Remote Interface
Kit (optional), the monitor can be controlled from
personal computers via the RS-422A serial interface.
Functions
Underscan mode
The signal normally scanned outside of the screen can
be monitored in the underscan mode.
Note
When the monitor is in the underscan mode, the dark
RGB scanning lines may appear on the top edge of the
screen. These are caused by an internal test signal,
rather than the input signal.
Horizontal/vertical delay mode
The horizontal and vertical sync signals can be
checked simultaneously in the H/V delay mode.
Auto/manual degaussing
Degaussing of the screen can be performed
automatically when the power is turned on, or
manually by pressing the DEGAUSS button.
On-screen menus
You can set color temperature, CHROMA SET UP,
and other settings by using the on-screen menus.
