COMPONENT SDI IN
BNC connector (×1)
Serial digital (270M bits/s)
SMPTE 259M/CCIR 656-III
Quantization: 10 bits/sample
Frequency responce:
Y: 5.75 MHz, –3 dB
R-Y/B-Y: 2.75 MHz, –3 dB
REMOTE 20-pin connector (×1)
See the pin assignment on page 14(E).
Outputs
LINE A/B
VIDEO OUT BNC connector (×2) loop-through,
Automatic 75 ohms termination
AUDIO OUT Phono jack (×2) loop-through
LINE C
Y/C OUT 4-pin mini-DIN (×1) loop-through,
Automatic 75 ohms termination
AUDIO OUT Phono jack (×1) loop-through
RGB/COMPONENT
R/R-Y,G/Y,B/B-Y OUT
BNC connector (×3)
loop-through
Automatic 75 ohms termination
AUDIO OUT Phono jack (×1) loop-through
EXT SYNC OUT BNC connector (×1)
Automatic 75 ohms termination
COMPONENT SDI OUT
BNC connector (×1)
Active loop-through output
Serial digital (270M bits/s)
SMPTE 259M/CCIR 656-III
Speaker output Output level: 0.8 W
General
CRT EBU phosphor
Power consumption 99 W
Power requirements 100 to 240 V AC, 50/60Hz
Operating temperature
0 to +35°C (32 to 95°F)
Storage temperature –10 to +40°C (14 to104°F)
Operating humidity 35 to 85% (no condensation)
Storage humidity 0 to 90%
Dimensions (w/h/d) Approx. 346 × 340 × 431 mm
(13
5
⁄8 × 13
1
⁄2 × 17 inches)
not incl. projecting parts and controls
Mass Approx. 17.7kg (39 lb)
Accessory supplied AC power cord (1)
AC plug holder (1)
Tally label (1)
Cable with a 20-pin connector (1)
Operation Manual (1)
Design and specifications are subject to change
without notice.
Specifications
Video signal
Color system PAL, NTSC, SECAM, NTSC4.43
Resolution 800 TV lines
Aperture correction 0 dB to +6 dB
Frequency response
LINE 10 MHz ± 3 dB (Y signal)
RGB 10 MHz ± 3 dB
Synchronization AFC time constant 1.0 msec.
Picture performance
Normal scan 7 % over scan of CRT effective screen
area
Under scan 5 % underscan of CRT effective screen
area
H. linearity Less than 4.0 % (typical)
V. linearity Less than 4.0 % (typical)
Convergence
Central area: 0.4 mm (typical)
Peripheral area: 0.5 mm (typical)
Raster size stability H: 1.0%, V: 1.5%
High voltage regulation
3.5 %
Color temperature D65/D93, selectable
USER (3,200K–10,000K, factory
setting is D65)
Inputs
LINE A/B
VIDEO IN BNC connector (×2), 1Vp-p ±6 dB,
sync negative
AUDIO IN Phono jack (×2), –5 dBu
a)
, more than
47 kilo-ohms
LINE C
Y/C IN 4-pin mini-DIN (×1)
See the pin assignment on page 14(E).
AUDIO IN Phono jack (×1), –5 dBu
a)
, more than
47 kilo-ohms
RGB/COMPONENT
R/R-Y,G/Y,B/B-Y IN: BNC connector (×3)
R, G, B channels: 0.7 Vp-p, ±6 dB
Sync on green: 0.3 Vp-p, negative
R-Y, B-Y channels: 0.7 Vp-p, ±6 dB
Y channel: 0.7 Vp-p, ±6 dB
(Standard color bar signal of 75%
chrominance)
AUDIO IN Phono jack (×1), –5 dBu
a)
, more than
47 kilo-ohms
EXT SYNC IN BNC connector (×1)
4 Vp-p, ±6 dB, sync negative
a) 0 dBu = 0.775 Vr.m.s.
