20
Chapter 2 Menus
Menu Structure
About menu numbers
In this manual, menu numbers are used to classify the
menus and show the route that you follow to reach any
particular menu.
A menu number consists of a letter (alphabetical
character) followed by one or more digits. The letter
identifies the menu group (see the preceding page),
and the digits indicate selections to be made on the
respective menu levels.
For example, the menu number A1321 shows that you
can reach the menu by making selections on the
respective menu levels as follows.
Select CONTROL PRESET ADJ in the
main menu.
Select the 1st item on menu level 1.
Select the 3rd item on menu level 2.
Select the 2nd item on menu level 3.
Select the 1st item on menu level 4.
e.g. A1321
Note
The menu numbers are merely for convenience of
explanation. They do not appear on the screen of your
monitor.
ADDRESS Menu
In addition to the menus listed in the table, the
ADDRESS menu is provided. This ADDRESS menu
is used to select the monitor or the monitor group, so
that when several monitors are connected together via
serial remote ports, the control panel can select which
monitor to control.
To display or exit the ADDRESS menu, press the
ADDRESS button. The method of choosing menu
items and changing settings is the same as with the
other menus.
For details of the ADDRESS menu, see “Selecting the
Monitor to Control —ADDRESS Menu” on page 54.
To Next Page
