Sony TRINITRON BVM-20F1U, BVM-20F1E, BVM-20E1U, BVM-20E1E, BVM-14F1U, BVM-14F1E, BVM-14E1U, BVM-14E1E, BVM-14F5U, BVM-14F5E, BVM-14E5 - Page 63

59
Chapter 3 Appendix
REMOTE 2
D-sub 9-pin, 1 (with loop-
through output)
ISR
D-sub 9-pin, 1
Video Signal
Differential gain Less than 2% (for luminance from
0 to 100 cd/m
2
)
Differential phase Less than 2˚ (for luminance from 0
to 100 cd/m
2
)
Frequency response
50 Hz to 10 MHz, ±1 dB
DC restoration Back porch type
Black level fluctuation: less than
1% for 10 to 90% APL input
signal variation.
Synchronization
AFC time Constant
0.5 ms (fast mode)
2 ms (normal mode)
Line pull range/line hold range
Greater than ±500 Hz (with 0.5 ms
AFC time constant)
Vertical blanking time
Normal: less than 1 ms.
Underscan: less than 0.8 ms
Horizontal blanking time
Less than 10 µs
Picture Performance
Normal scan 5% overscan of CRT effective
screen area (adjustable range
greater than ±15%)
Underscan 3% underscan of CRT effective
screen area (adjustable range
greater than ±15%)
Linearity Within a central area bounded by a
circle with a diameter equal to the
picture height, less than 0.5% of
the picture height, and outside the
same area, about 1% of the
picture height
Color temperature
D65, D93 (adjustable to other color
temperatures)
Convergence error
Within a central area bounded by a
circle with a diameter equal to the
picture height:
Less than 0.4 mm (BVM-20F1U/
20F1E/20E1U/20E1E)
Less than 0.3 mm (BVM-14F1U/
14F1E/14E1U/14E1E/14F5U/
14F5E/14E5U/14E5E)
Outer area of the above-mentioned
circle:
Less than 0.7 mm (BVM-20F1U/
20F1E/20E1U/20E1E)
Less than 0.6 mm (BVM-14F1U/
14F1E/14E1U/14E1E/14F5U/
14F5E/14E5U/14E5E)
Standard luminescence
100 cd/m
2
(at standard 1 Vp-p
100% white signal)
Raster size stability
Less than 1% of picture height (at
100 cd/m
2
peak luminescence, 10
to 90% APL)
Scan delay Horizontal: Approx.
1
/
4
line
Vertical: Approx.
1
/
2
field
Resolution (at screen center, 100 cd/m
2
luminescence)
BVM-20F1U/20F1E: 900 TV lines
BVM-20E1U/20E1E: 1000 TV
lines
BVM-14F1U/14F1E/14F5U/
14F5E: 800 TV lines
BVM-14E1U/14E1E/14E5U/
14E5E: 900 TV lines
Operating Conditions
Temperature 0°C to 35°C (32°C to 95°F)
Optimum temperature
20°C to 30°C (68°F to 86°F)
Humidity 0% to 90% (no condensation)
Pressure 700 hPa to 1060 hPa
Storage and transport conditions
Temperature –10 °C to +40°C (14°F to 104°F)
Humidity 0% to 90%
Pressure 700 hPa to 1060 hPa
