— 45 —
The components identified by shading
and mark
are critical for safety.
Replace only with part number specified.
Note: Note:
The components identified by in this manual have been
carefully factory-selected for each set in order to satisfy
regulations regarding x-ray radiation. Should replacement
be required, replace only with the value originally used.
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
CPD-E210
D
R918 1-240-981-91 METAL CHIP 1K 5% 1/10W
R919 1-240-969-91 METAL CHIP 100 5% 1/10W
R920 1-240-981-91 METAL CHIP 1K 5% 1/10W
R921 1-216-295-91 SHORT
R922 1-240-993-91 METAL CHIP 10K 5% 1/10W
R923 1-216-295-91 SHORT
R924 1-240-969-91 METAL CHIP 100 5% 1/10W
R925 1-242-776-91 METAL CHIP 470K 5% 1/10W
R926 1-240-969-91 METAL CHIP 100 5% 1/10W
R927 1-216-295-91 SHORT
R928 1-240-969-91 METAL CHIP 100 5% 1/10W
R929 1-240-985-91 METAL CHIP 2.2K 5% 1/10W
R931 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R932 1-240-995-91 METAL CHIP 15K 5% 1/10W
R933 1-247-831-91 CARBON 1K 5% 1/4W
R934 1-249-429-11 CARBON 10K 5% 1/4W
R935 1-240-969-91 METAL CHIP 100 5% 1/10W
R936 1-240-969-91 METAL CHIP 100 5% 1/10W
R937 1-240-969-91 METAL CHIP 100 5% 1/10W
R938 1-240-969-91 METAL CHIP 100 5% 1/10W
R940 1-216-661-11 METAL CHIP 2.7K 0.50% 1/10W
R943 1-249-413-11 CARBON 470 5% 1/4W
R950 1-240-982-91 METAL CHIP 1.2K 5% 1/10W
R951 1-240-969-91 METAL CHIP 100 5% 1/10W
R953 1-240-993-91 METAL CHIP 10K 5% 1/10W
R954 1-240-993-91 METAL CHIP 10K 5% 1/10W
R957 1-240-965-91 METAL CHIP 47 5% 1/10W
R958 1-240-965-91 METAL CHIP 47 5% 1/10W
VARIABLE RESISTOR
RV501 1-241-767-21 RES, ADJ, CERMET 100K
3-710-578-01 COVER, VOLUME, 6 MOLD
RELAY
RY500 1-755-137-11 RELAY
RY601 1-755-067-21 RELAY
SWITCH
S602 1-771-757-11 SWITCH, PUSH (1 KEY)
S901 1-692-431-21 SWITCH, TACTILE
SPARK GAP
SG501 1-519-422-11 GAP, SPARK
TRANSFORMER
T501 1-453-311-11 FBT ASSY NX-4404//X4L4
T503 1-433-979-11 TRANSFORMER, FERRITE (DFT)
T504 1-433-978-11 TRANSFORMER, FERRITE
T505 1-431-413-11 TRANSFORMER, FERRITE (HST)
T601 1-433-847-14 TRANSFORMER, CONVERTER (SRT)
THERMISTOR
TH501 1-807-796-11 THERMISTOR
TH600 1-809-827-11 THERMISTOR, NTC
TH601 1-803-540-11 THERMISTOR
VARISTOR
VA601 1-801-073-31 VARISTOR TNR14V471K660
CRYSTAL
X901 1-767-641-11 VIBRATOR, CRYSTAL
X902 1-767-933-11 OSCILLATOR, CERAMIC
* A-1372-697-A H MOUNTED PC BOARD
CAPACITOR
C801 1-104-664-11 ELECT 47µF 20% 10V
CONNECTOR
CN801 * 1-564-510-11 PLUG, CONNECTOR 7P
DIODE
D803 8-719-064-11 DIODE SPR-325MVW
TRANSISTOR
Q801 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q802 8-729-119-78 TRANSISTOR 2SC2785-HFE
RESISTOR
R801 1-215-417-00 METAL 680 1% 1/4W
R802 1-215-421-00 METAL 1K 1% 1/4W
R803 1-215-427-00 METAL 1.8K 1% 1/4W
R804 1-215-433-00 METAL 3.3K 1% 1/4W
To Next Page
