REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
51
C1208 1-126-953-11 ELECT 2200UF 20.00% 35V
C1209 1-163-033-91 CERAMIC CHIP 0.022UF 50V
C1210 1-126-960-11 ELECT 1UF 20.00% 50V
C1211 1-163-033-91 CERAMIC CHIP 0.022UF 50V
C1213 1-164-346-91 CERAMIC CHIP 1UF 16V
C1215 1-126-952-11 ELECT 1000UF 20.00% 35V
C1218 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C1219 1-104-666-11 ELECT 220UF 20.00% 25V
C1221 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1228 1-126-952-11 ELECT 1000UF 20.00% 35V
C1229 1-163-001-11 CERAMIC CHIP 220PF 10.00% 50V
C1230 1-163-001-11 CERAMIC CHIP 220PF 10.00% 50V
C1232 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1235 1-126-960-11 ELECT 1UF 20.00% 50V
C1236 1-126-960-11 ELECT 1UF 20.00% 50V
< CONNECTOR >
CN001 *1-564-508-11 PLUG, CONNECTOR 5P
CN003 *1-564-510-51 PLUG, CONNECTOR 7P
CN405 *1-564-510-11 PLUG, CONNECTOR 7P
CN406 *1-564-512-11 PLUG, CONNECTOR 9P
CN501 1-580-798-11 CONNECTOR PIN (DY)
CN503 *1-564-506-11 PLUG, CONNECTOR 3P
CN506 1-695-915-11 TAB (CONTACT)
CN508 *1-564-508-11 PLUG, CONNECTOR 5P
CN509 1-695-915-11 TAB (CONTACT)
CN510 1-691-771-11 PLUG (MICRO CONNECTOR) 9P
CN512 *1-770-723-11 CONNECTOR, BOARD TO BOARD 8P
CN602 1-508-765-00 PIN, CONNECTOR (5MM PITCH) 3P
CN603 *1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P
CN605 *1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN606 *1-695-292-11 PIN, CONNECTOR (POWER)
CN1200 *1-564-509-11 PLUG, CONNECTOR 6P
CN1201 *1-564-507-11 PLUG, CONNECTOR 4P
CN1202 *1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D001 8-719-069-55 DIODE UDZSTE-175.6B
D002 8-719-069-55 DIODE UDZSTE-175.6B
D003 8-719-109-69 DIODE RD3.6ES-B2
D005 8-719-929-15 DIODE HZS9.1NB2
D006 8-719-109-89 DIODE RD5.6ESB2
D007 8-719-069-55 DIODE UDZSTE-175.6B
D008 8-719-074-43 DIODE BAS316-115
D010 8-719-074-43 DIODE BAS316-115
D011 8-719-074-43 DIODE BAS316-115
D012 8-719-929-15 DIODE HZS9.1NB2
D013 8-719-109-69 DIODE RD3.6ES-B2
D014 1-216-295-91 SHORT 0
D016 8-719-109-89 DIODE RD5.6ESB2
B1
A
D018 8-719-109-69 DIODE RD3.6ES-B2
D019 8-719-978-33 DIODE DTZ-TT116.8B
D021 8-719-978-33 DIODE DTZ-TT116.8B
D022 8-719-069-55 DIODE UDZSTE-175.6B
D035 8-719-069-55 DIODE UDZSTE-175.6B
D036 8-719-069-55 DIODE UDZSTE-175.6B
D051 8-719-081-98 DIODE MM3Z6V8T1
D101 8-719-977-81 DIODE DTZ33B
D103 8-719-081-98 DIODE MM3Z6V8T1
D104 8-719-069-55 DIODE UDZSTE-175.6B
D105 8-719-069-55 DIODE UDZSTE-175.6B
D106 8-719-069-55 DIODE UDZSTE-175.6B
D107 8-719-069-55 DIODE UDZSTE-175.6B
D207 8-719-069-60 DIODE UDZSTE-179.1B
D210 8-719-069-55 DIODE UDZSTE-175.6B
D211 8-719-069-60 DIODE UDZSTE-179.1B
D212 8-719-914-43 DIODE DAN202K
D228 8-719-069-55 DIODE UDZSTE-175.6B
D235 8-719-069-55 DIODE UDZSTE-175.6B
D236 8-719-069-60 DIODE UDZSTE-179.1B
D401 8-719-069-57 DIODE UDZSTE-176.8B
D402 8-719-081-98 DIODE MM3Z6V8T1
D403 8-719-978-33 DIODE DTZ-TT116.8B
D404 8-719-109-89 DIODE RD5.6ESB2
D405 8-719-081-98 DIODE MM3Z6V8T1
D406 8-719-081-98 DIODE MM3Z6V8T1
D407 8-719-081-98 DIODE MM3Z6V8T1
D408 8-719-069-57 DIODE UDZSTE-176.8B
D410 8-719-069-57 DIODE UDZSTE-176.8B
D411 8-719-069-57 DIODE UDZSTE-176.8B
D412 8-719-081-98 DIODE MM3Z6V8T1
D413 8-719-069-57 DIODE UDZSTE-176.8B
D414 8-719-081-98 DIODE MM3Z6V8T1
D418 8-719-069-60 DIODE UDZSTE-179.1B
D419 8-719-049-26 DIODE RB721Q
D420 8-719-081-98 DIODE MM3Z6V8T1
D421 8-719-049-26 DIODE RB721Q
D422 8-719-069-57 DIODE UDZSTE-176.8B
D423 8-719-081-98 DIODE MM3Z6V8T1
D424 8-719-069-60 DIODE UDZSTE-179.1B
D427 8-719-082-01 DIODE MM3Z12VT1
D428 8-719-069-57 DIODE UDZSTE-176.8B
D429 8-719-069-57 DIODE UDZSTE-176.8B
D435 8-719-069-60 DIODE UDZSTE-179.1B
D436 8-719-069-60 DIODE UDZSTE-179.1B
D501 8-719-979-85 DIODE EGP20G
D502 8-719-081-90 DIODE PDZ22B-115
D503 8-719-069-55 DIODE UDZSTE-175.6B
D504 8-719-074-43 DIODE BAS316-115
D512 8-719-302-43 DIODE EL1Z
