Sony Trinitron KV-24LS35B - Page 41

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
53
Q1232 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q1233 8-729-026-49 TRANSISTOR 2SA1037AK-T146
< RESISTOR >
JR3 1-216-296-11 SHORT 0
JR4 1-216-295-91 SHORT 0
JR5 1-216-295-91 SHORT 0
JR5 1-216-295-91 SHORT 0
JR7 1-216-295-91 SHORT 0
JR9 1-216-295-91 SHORT 0
JR10 1-216-295-91 SHORT 0
JR16 1-216-296-11 SHORT 0
JR17 1-216-295-91 SHORT 0
JR21 1-216-818-11 RES-CHIP 560 5% 1/16W
JR24 1-216-295-91 SHORT 0
JR25 1-216-295-91 SHORT 0
JR26 1-216-295-91 SHORT 0
JR101 1-216-295-91 SHORT 0
JR105 1-216-295-91 SHORT 0
JR204 1-216-296-11 SHORT 0
JR206 1-216-295-91 SHORT 0
JR208 1-216-295-91 SHORT 0
JR209 1-216-295-91 SHORT 0
JR210 1-216-295-91 SHORT 0
JR211 1-216-296-11 SHORT 0
JR213 1-216-295-91 SHORT 0
JR401 1-216-295-91 SHORT 0
JR418 1-216-296-11 SHORT 0
JR423 1-216-296-11 SHORT 0
JR505 1-216-295-91 SHORT 0
JR506 1-216-238-91 RES-CHIP 47K
JR601 1-216-295-91 SHORT 0
JR609 1-216-295-91 SHORT 0
JR610 1-216-295-91 SHORT 0
JR1209 1-216-295-91 SHORT 0
R001 1-216-295-91 SHORT 0
R003 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R004 1-216-033-00 RES-CHIP 220 5% 1/10W
R005 1-216-041-00 RES-CHIP 470 5% 1/10W
R006 1-216-025-11 RES-CHIP 100 5% 1/10W
R007 1-216-025-11 RES-CHIP 100 5% 1/10W
R008 1-216-025-11 RES-CHIP 100 5% 1/10W
R009 1-216-049-11 RES-CHIP 1K 5% 1/10W
R010 1-216-049-11 RES-CHIP 1K 5% 1/10W
R011 1-216-295-91 SHORT 0
R012 1-216-121-11 RES-CHIP 1M 5% 1/10W
R014 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R015 1-216-198-91 RES-CHIP 1K 5% 1/8W
R017 1-216-025-11 RES-CHIP 100 5% 1/10W
A
L502 1-412-529-11 INDUCTOR 22UH
L503 1-412-521-31 INDUCTOR 4.7UH
L504 1-535-143-61 LEAD, JUMPER (5.0MM)
L505 1-412-542-41 INDUCTOR 270UH
L507 1-412-533-21 INDUCTOR 47UH
L532 1-412-553-11 INDUCTOR 3.3MH
L533 1-406-989-21 INDUCTOR 10MH
L534 1-216-025-11 RES-CHIP 100 5% 1/10W
L535 1-459-111-00 INDUCTOR 10MH
L537 1-424-870-11 COIL HOR LINEARITY
L601 1-408-603-31 INDUCTOR 10UH
L602 1-408-611-31 INDUCTOR 47UH
L603 1-412-523-41 INDUCTOR 6.8UH
L1201 1-535-143-61 LEAD, JUMPER (5.0MM)
L1203 1-535-143-61 LEAD, JUMPER (5.0MM)
< PHOTO COUPLER >
PH601 £ 8-749-016-21 IC TCET1103G
< IC LINK >
PS1201 £ 1-533-597-31 LINK, IC
< TRANSISTOR >
Q002 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q013 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q014 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q049 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q202 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q203 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q212 8-729-422-33 TRANSISTOR 2SD601A-Q-TX
Q401 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q409 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q411 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q532 8-729-053-33 TRANSISTOR IRF614-037
Q533 8-729-049-08 TRANSISTOR BU2515DX-127
Q535 8-729-053-33 TRANSISTOR IRF614-037
Q576 8-729-422-33 TRANSISTOR 2SD601A-Q-TX
Q601 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q602 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q603 8-729-029-56 TRANSISTOR DTA144ESA
Q604 8-729-030-02 TRANSISTOR DTC144ESA
Q606 8-729-053-36 TRANSISTOR 2SK2640-01MR
Q607 8-729-053-36 TRANSISTOR 2SK2640-01MR
Q608 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q609 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q1210 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1211 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1230 8-729-027-56 TRANSISTOR DTC143TKA-T146
Q1231 8-729-027-56 TRANSISTOR DTC143TKA-T146
