KV-25C5/29C5
[A
REF.NO.
PART.NO
DESCRIPTION
REMARK
REFNO.
—
PART.NO
DESCRIPTION
REMARK
R082 1-216-053-00 RES, CHIP 1.5K 53 1/10W
R083 1-216-031-00 RES, CHIP 180 5% 1/108
R084 1-216-053-00 RES,CHIP 1.5K 5% 1/108
R085 1-216-031-00 RES,CHIP 180 5% 1/10W
R086 1-216-053-00 RES,CHIP 1.5K 53 1/10W
R154 1-216-238-91 RES, CHIP 47K 5%) 1/88
R155 1-216-089-00 RES ,CHIP Am 5% 1/10W
R156 1-216-073-00 RES,CHIP 10K 53 = 1/10W
(KV-25C5B/29C5B)
R157 1-216-063-91 RES, CHIP 3.9K 58 1/10W
(KV-25C5B/29C5B)
R087 1-216-180-00 RES,CHIP 180 5% 1/8"
R088 1-216-065-00 RES, CHIP 4.7K 5% = 1/10W
R089 1-216-081-00 RES, CHIP 22K «5% = 1/10H
(KV-29C5A/29C5B/29C5D/29C5E/29C5K/29C5R)
R090 1-216-057-00 RES, CHIP 2.2K 5% 1/108
(KV-29C5A/29C5B/29C5D/29C5E/29C5K/29C5R)
R158 1-216-069-00 RES, CHIP 6.8K 5% 1/100
(KV-25C5B/29C5B)
R204 1-247-863-91 CARBON 22K 5%) /4W
R206 1-216-085-00 RES,CHIP 33K 5%) =—1/10W
R207 1-216-295-00 SHORT 0
R091 1-216-081-00 RES,CHIP 22K 53) 1 /10W
(KV-29C5A/29C5B/29C5D/29C5E/29C5K/29C5R)
R092 1-216-073-00 RES, CHIP 10K 5% = 1/10W
(KV-29C5A/29C5B/29C5D/29C5E/29C5K/29C5R)
R093 1-216-230-00 RES, CHIP 22K «5% ~=—1/8W
R209 1-216-065-00 RES, CHIP 4.7K 5% = 1/10W
R211 1-215-873-00 METAL OXIDE 4.7K 5¢ IW fF
R213 1-216-089-00 RES,CHIP 47K 5% = 1/100
R301 1-216-025-00 RES, CHIP 100 5% = 1/100
R302 1-216-081-00 RES,CHIP 22K 5%) «A /10W
R094 1-216-057-00 RES, CHIP 2.2K 53 = 1/10W
R095 1-216-025-00 RES,CHIP 100 53 = 1/100
R303 1-216-073-00 RES, CHIP 10K 5%) /10W
R304 1-216-073-00 RES,CHIP 10K 05% = 1/10W
R096
1-247-807-31
CARBON
100
53
=
1/4
R306
1-216-206-00
RES,CHIP
2.2K
58
=
1/8H
R097
1-247-807-31
CARBON
100
5%
=
«1/4
R309
1-216-675-11
METAL
CHIP
10K
0.50%
1/10W
R098
1-247-807-31
CARBON
100
53
=
(1/4
R310
1-216-022-00
RES,
CHIP
7
5%
1/10W
R099
1-247-807-31
CARBON
100
5%
=
1/4W
R311
1-216-022-00
RES,
CHIP
75
581/10
R101 1-216-049-00 RES, CHIP 1K 58 )—1/10W
R106 1-215-900-11 METAL OXIDE 22K 5% QW fF
R110 1-216-296-91 SHORT 0 (KV-25C5B/29CS5B)
R111 1-216-057-00 RES, CHIP 2.2K 53 = 1/10W
(KV-25C5B/29C5B)
R313 1-216-025-00 RES,CHIP 100 5% = 1/10W
R314 1-216-025-00 RES, CHIP 100 58 = 1/10W
R315 1-216-075-91 RES, CHIP 12K 5% = 1/10
R316 1-216-025-00 RES, CHIP 100 5% = 1/10W
R317 1-216-049-00 RES, CHIP 1K 5% 1/10W
R318 1-216-025-00 RES, CHIP 100 5% = 1/10W
R319 1-216-025-00 RES, CHIP 100 5% = 1/10
R112 1-216-057-00 RES, CHIP 2.2K 58 —1/10W
(KV-25C5B/29C5B)
R116 1-249-437-11 CARBON 47K 581 /4W R320 1-216-025-00 RES, CHIP 100 53 = 1/108
(KV-25C5E/25C5K/29C5E/29C5K) R321 1-216-025-00 RES,CHIP 100 «58 = «1/10
R120 1-216-037-00 RES, CHIP 330 58 = 1/10W
R323 1-216-025-00 RES, CHIP 100 5% 1/10W
R324 1-412-002-21 INDUCTOR 4.7UH 53 = 1/10W
R325 1-412-002-21 INDUCTOR 4.70H 53 1/10W
R326 1-216-129-00 RES, CHIP 2.2M 5% = 1/10W
R327 1-216-295-00 SHORT 0
R121 1-216-025-00 RES, CHIP 100 58 = .1/10W
R122 1~216-025-00 RES,CHIP 100 5% = 1/10W
R127 1-216-031-00 RES, CHIP 180 53 1/108
(KV-25C5B/29C5B)
R128 1-216-065-00 RES,CHIP 4.7K 5% = 1/10W
(KV-25C5B/29C5B) R331 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R332 1-216-057-00 RES,CHIP 2.2K 53 = 1/10W
R333 1-216-057-00 RES,CHIP 2.2K 5% = 1/10W
R334 1-216-025-00 RES, CHIP 100 5% 1/10W
R129 1-216-063-91 RES, CHIP 3.9K 5$ 1/10W
(KV-25C5B/29C5B)
R133 1-216~295-00 SHORT Q (KV-25C5A/25C5D/25C5E/25C5K/ R335, 1-216-025-00 RES, CHIP 100 5% = 1/10W
25C5R/29C5A/29C5D/29C5E/
29C5K/29C5R) R337 1-216-065-00 RES, CHIP 4.7K 5% = 1/10W
R338 1-216-049-00 RES, CHIP 1K 581/100
R142 1-216-295-00 SHORT 0 R401 1-216-113-00 RES, CHIP 470K 53 1/10
R143 1-216-025-00 RES, CHIP 100 «5% = 1/10W
R144 1-216-079-00 RES, CHIP 18K 65% = 1/10W
R145 1-216-212-00 RES, CHIP 3.9K 5% 1/8H
R147 1-216-017-91 RES,CHIP 47 5% 1/10
(KV-25C5B/29C5B)
R403 1-216-041-00 RES,CHIP 470 5% 1/10W
R404 1-216-113-00 RES,CHIP 470K 5% 1/10W
R405 1-216-295-00 SHORT 0
R406 1-216-113-00 RES,CHIP 470K 5% = 1/10W
R408 1-216-022-00 RES,CHIP 75 «5% = 1/10W
R409 1-216-029-71 RES, CHIP 150 5% 1/10W
R410 1-216-029-71 RES, CHIP 150 53 1/10W
R148 1-216-174-00 RES, CHIP 100 «58 = «1/88
(KV-25C5B/29C5B)
R149 1-216-049-00 RES, CHIP 1K 58/10
(KV-25C5B/29C5B)
R151 1-216-049-00 RES, CHIP 1K 5%) 1/10W
R411 1-216-022-00 RES,CHIP 75 858 = 1/10W
R412 1-216-029-71 RES, CRIP 150 53 1/10W
R413 1-216-295-00 SHORT 0
R414 1-216-022-00 RES, CHIP 75 5% 1/10W
R415 1-216-022-00 RES, CHIP 75 «65% = 1/10W
R152 1-21 6-025-00 RES, CHIP 100 53 = 1/10W
(KV-25C5B/29C5B}
R153 1-216-180-00 RES, CHIP 180 53 1/8
(KV-25C5B/29C5B) R417 1-260-158-11 CARBON 75 5% = (3/2
63
