Sony TRINITRON KV-29FX11E - Signal Waveform Examples; D Board Signal Waveforms; C Board Signal Waveforms; A Board Signal Waveforms

3
5
2.6 Vp-p (H) 56 Vp-p (V)
6
1.2K Vp-p (H)
1
56.0 Vp-p (V)
2
WAVEFORMS D BOARD
13 Vp-p (H)
3
31 Vp-p (V)
7
178 Vp-p (H)
4
140 Vp-p (H)
8
1.0 Vp-p (H)
9
28 Vp-p (H)
10
3.0 Vp-p (H)
11
12
5.5 Vp-p (V)
5
1.0 Vp-p (H) 1.4 Vp-p (H)
6
3.5 Vp-p (H)
1
3.0 Vp-p (H)
2
WAVEFORMS A BOARD
1.5 Vp-p (H)
8
0.9 Vp-p (H)
8
3.0 Vp-p (H)
3
0.6 Vp-p (H)
7
0.5 Vp-p (H)
9
PAL/SECAM
PAL/NTSC
0.5 Vp-p (H)
7
2.3 Vp-p (H)
3
0.4 Vp-p (H)
9
5.1 Vp-p (H)
4
0.8 Vp-p (H)
8
1.0 Vp-p (H)
10
NTSC
SECAM PAL
SECAM NTSC PAL/SECAM NTSC
110 Vp-p (H) 108 Vp-p (H)
WAVEFORMS C BOARD
90 Vp-p (H) 21 Vp-p (H)
1 2 3 4
