Sony TRINITRON KV-29FX11E - D Board Component List (Resistors & IC Links); D Board Resistors (R500-R631 A); D Board IC Links, Transistors, Resistors

86
K
V-29FX11
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
D
L609 1-412-533-21 INDUCTOR 47UH
L610 1-535-465-11 LEAD, JUMPER (5.0MM)
L611 1-412-527-11 INDUCTOR 15UH
L612 1-412-522-41 INDUCTOR 5.6UH
L613 1-412-522-41 INDUCTOR 5.6UH
L615 1-412-529-11 INDUCTOR 22UH
L616 1-412-533-21 INDUCTOR 47UH
L801 1-459-111-00 INDUCTOR 0UH
L802 1-459-104-00 COIL, WITH CORE
L803 1-535-465-11 LEAD, JUMPER (5.0MM)
L805 1-406-674-11 INDUCTOR 0UH
L806 1-535-465-11 LEAD, JUMPER (5.0MM)
L809 1-408-611-31 INDUCTOR 47UH
L810 1-535-465-11 LEAD, JUMPER (5.0MM)
L811 1-406-978-11 INDUCTOR 0UH
L813 1-412-552-11 INDUCTOR 2.2MMH
L901 1-408-603-31 INDUCTOR 10UH
L902 1-408-603-31 INDUCTOR 10UH
L903 1-408-591-41 INDUCTOR 1UH
L904 1-408-591-41 INDUCTOR 1UH
< IC LINK >
PS600 £ 1-532-686-21 LINK, IC 2.7A (ICP-F75)
PS601 £ 1-532-686-21 LINK, IC 2.7A (ICP-F75)
PS602 £ 1-532-686-21 LINK, IC 2.7A (ICP-F75)
PS603 £ 1-532-686-21 LINK, IC 2.7A (ICP-F75)
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q503 8-729-030-02 TRANSISTOR DTC144ESA
Q601 8-729-025-04 TRANSISTOR 2SC3852A
Q602 8-729-320-28 TRANSISTOR 2SA1667
Q603 8-729-805-05 TRANSISTOR 2SC3601-E
Q604 8-729-024-35 TRANSISTOR 2SC2808STP-R
Q605 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q606 8-729-900-65 TRANSISTOR DTA144ES
Q607 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q801 8-729-039-68 TRANSISTOR IRF620
Q802 8-729-042-86 TRANSISTOR 2SC5251-01
Q803 8-729-119-80 TRANSISTOR 2SC2688-LK
Q805 8-729-030-02 TRANSISTOR DTC144ESA
Q900 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1200 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1201 8-729-029-94 TRANSISTOR DTC143TSA
Q1202 8-729-029-66 TRANSISTOR DTC114ESA
Q1203 8-729-029-94 TRANSISTOR DTC143TSA
Q1204 8-729-029-94 TRANSISTOR DTC143TSA
< RESISTOR >
R500 1-215-457-00 METAL 33K 1% 1/4W
R502 1-249-421-11 CARBON 2.2K 5% 1/4W
R503 1-249-429-11 CARBON 10K 5% 1/4W
R504 1-215-457-00 METAL 33K 1% 1/4W
R505 1-249-382-11 CARBON 1.2 5% 1/4W F
R506 1-215-437-00 METAL 4.7K 1% 1/4W
R507 1-215-888-00 METAL OXIDE 220 5% 2W F
R508 1-216-371-00 METAL OXIDE 1.5 5% 2W F
R509 1-249-443-11 CARBON 0.47 5% 1/4W F
R510 1-249-443-11 CARBON 0.47 5% 1/4W F
R519 1-215-445-00 METAL 10K 1% 1/4W
R520 1-215-451-00 METAL 18K 1% 1/4W
R521 1-215-455-00 METAL 27K 1% 1/4W
R522 1-247-863-91 CARBON 22K 5% 1/4W
R523 1-247-863-91 CARBON 22K 5% 1/4W
R524 1-249-425-11 CARBON 4.7K 5% 1/4W
R525 1-249-425-11 CARBON 4.7K 5% 1/4W
R526 1-249-421-11 CARBON 2.2K 5% 1/4W
R527 1-215-437-00 METAL 4.7K 1% 1/4W
R600 £ 1-216-490-11 METAL OXIDE 39K 5% 3W F
R601 1-249-417-11 CARBON 1K 5% 1/4W
R602 1-215-473-00 METAL 150K 1% 1/4W
R603 1-215-898-11 METAL OXIDE 10K 5% 2W F
R604 1-249-420-11 CARBON 1.8K 5% 1/4W
R605 1-216-362-11 METAL OXIDE 0.27 5% 2W F
R606 1-535-143-21 LEAD, JUMPER (12.5MM)
R607 1-216-421-11 METAL OXIDE 12 5% 1W F
R608 1-216-365-00 METAL OXIDE 0.47 5% 2W F
R609 1-535-465-11 LEAD, JUMPER (5.0MM)
R610 1-215-429-00 METAL 2.2K 1% 1/4W
R611 1-216-354-11 METAL OXIDE 2.7 5% 1W F
R612 1-249-428-11 CARBON 8.2K 5% 1/4W
R613 1-249-417-11 CARBON 1K 5% 1/4W
R614 1-215-877-11 METAL OXIDE 22K 5% 1W F
R615 1-249-435-11 CARBON 33K 5% 1/4W
R616 1-215-471-00 METAL 120K 1% 1/4W
R617 1-215-901-00 METAL OXIDE 33K 5% 2W F
R618 1-247-863-91 CARBON 22K 5% 1/4W
R619 1-216-425-11 METAL OXIDE 56 5% 1W F
R620 1-260-131-11 CARBON 470K 5% 1/2W
R621 1-216-425-11 METAL OXIDE 56 5% 1W F
R622 1-249-437-11 CARBON 47K 5% 1/4W
R624 1-249-393-11 CARBON 10 5% 1/4W F
R625 1-249-434-11 CARBON 27K 5% 1/4W
R626 1-249-430-11 CARBON 12K 5% 1/4W
