REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 95 —
* A-1135-948-A B BOARD, COMPLETE
(KV-32V40 only)
* A-1135-949-A B BOARD, COMPLETE
(KV-34VL65C/32V65CND/34VL65/35V65CND/
37VL65/37VL65C only)
* A-1135-950-A B BOARD, COMPLETE
(KV-32S40/34SL40/34SL40C/32S45/34SL45/35S40/35S45/
37SL45/34SL40T only)
CAPACITOR
C3501 1-104-664-11 ELECT 47MF 20% 25V
C3502 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C3503 1-163-021-91 CERAMIC 0.01MF 10% 50V
C3504 1-126-964-11 ELECT 10MF 20% 50V
C3505 1-163-131-00 CERAMIC 390PF 5% 50V
C3506 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C3507 1-126-963-11 ELECT 4.7MF 20% 50V
C3508 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C3509 1-126-961-11 ELECT 2.2MF 20% 50V
C3510 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C3511 1-126-964-11 ELECT 10MF 20% 50V
C3512 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C3513 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C3514 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C3515 1-126-963-11 ELECT 4.7MF 20% 50V
C3516 1-163-089-00 CERAMIC CHIP 6PF 0.5PF 50V
C3517 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C3518 1-126-941-11 ELECT 470MF 20% 25V
C3519 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C3520 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C3521 1-104-664-11 ELECT 47MF 20% 25V
C3522 1-126-964-11 ELECT 10MF 20% 50V
C3523 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C3524 1-104-664-11 ELECT 47MF 20% 25V
C3525 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C3526 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C3527 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C3528 1-164-222-11 CERAMIC CHIP 0.22MF 25V
C3529 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C3530 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C3532 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C3533 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C3534 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C3535 1-104-664-11 ELECT 47MF 20% 25V
C3536 1-126-964-11 ELECT 10MF 20% 50V
C3537 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C3538 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C3539 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C3540 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C3541 1-104-664-11 ELECT 47MF 20% 25V
C3542 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C3543 1-104-664-11 ELECT 47MF 20% 25V
C3544 1-104-664-11 ELECT 47MF 20% 25V
C3545 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C3548 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C3549 1-126-964-11 ELECT 10MF 20% 50V
C3550 1-104-664-11 ELECT 47MF 20% 25V
C3551 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C3553 1-126-941-11 ELECT 470MF 20% 25V
C3556 1-128-551-11 ELECT 22MF 20% 25V
C3557 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
CONNECTOR
CN3502 * 1-573-978-21 CONNECTOR, BOARD TO BOARD 11P
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
CN3561 * 1-691-616-21 CONNECTOR, BOARD TO BOARD 15P
(KV-32V40/34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
CN3570 * 1-764-816-11 CONNECTOR, BOARD TO BOARD 20P
(KV-32S40/34SL40/34SL40C/32S45/34SL45/35S40/35S45/37SL45/34SL40T only)
FILTER
FL3501 1-239-847-11 FILTER, LOW PASS
FL3502 1-239-847-11 FILTER, LOW PASS
FL3503 1-239-847-11 FILTER, LOW PASS
IC
IC3501 8-759-065-82 IC MM1093ND
IC3502 8-752-385-80 IC CXD2073S
IC3503 8-759-231-53 IC TA7805S
COIL
L3501 1-410-470-11 INDUCTOR 10UH
L3502 1-410-466-41 INDUCTOR 4.7UH
L3503 1-410-470-11 INDUCTOR 10UH
L3504 1-410-470-11 INDUCTOR 10UH
L3505 1-410-470-11 INDUCTOR 10UH
COMPLETE PARTS LISTING
B
B
