Sony Trinitron KV-35V65 - B COMPLETE PARTS LISTING

REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
— 96 —
TRANSISTOR
Q3501 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3502 8-729-216-22 TRANSISTOR 2SA1162-G
Q3503 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3504 8-729-216-22 TRANSISTOR 2SA1162-G
Q3505 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3506 8-729-216-22 TRANSISTOR 2SA1162-G
Q3507 8-729-216-22 TRANSISTOR 2SA1162-G
Q3509 8-729-216-22 TRANSISTOR 2SA1162-G
Q3510 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3516 8-729-216-22 TRANSISTOR 2SA1162-G
Q3555 8-729-216-22 TRANSISTOR 2SA1162-G
RESISTOR
R3501 1-216-091-00 RES, CHIP 56K 5% 1/10W
R3502 1-216-081-00 RES, CHIP 22K 5% 1/10W
R3503 1-216-009-00 RES, CHIP 22 5% 1/10W
R3504 1-216-029-00 RES, CHIP 150 5% 1/10W
R3505 1-216-037-00 RES, CHIP 330 5% 1/10W
R3506 1-216-035-00 RES, CHIP 270 5% 1/10W
R3507 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R3508 1-216-043-91 RES, CHIP 560 5% 1/10W
R3509 1-216-075-00 RES, CHIP 12K 5% 1/10W
R3510 1-216-049-91 RES, CHIP 1K 5% 1/10W
R3511 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R3512 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R3513 1-216-041-00 RES, CHIP 470 5% 1/10W
R3514 1-216-121-91 RES, CHIP 1M 5% 1/10W
R3515 1-216-077-00 RES, CHIP 15K 5% 1/10W
R3516 1-216-037-00 RES, CHIP 330 5% 1/10W
R3517 1-216-077-00 RES, CHIP 15K 5% 1/10W
R3518 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R3520 1-208-766-11 RES, CHIP 220 0.50% 1/10W
R3521 1-208-766-11 RES, CHIP 220 0.50% 1/10W
R3522 1-208-774-11 RES, CHIP 470 0.50% 1/10W
R3523 1-208-778-11 RES, CHIP 680 0.50% 1/10W
R3524 1-208-794-11 RES, CHIP 3.3K 0.50% 1/10W
R3526 1-208-776-11 RES, CHIP 560 0.50% 1/10W
R3527 1-208-824-11 RES, CHIP 56K 0.50% 1/10W
R3529 1-216-295-91 SHORT
R3531 1-216-295-91 SHORT
R3534 1-216-295-91 SHORT
R3535 1-216-295-91 SHORT
R3536 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R3537 1-216-043-91 RES, CHIP 560 5% 1/10W
R3538 1-216-071-00 RES, CHIP 8.2K 5% 1/10W
R3539 1-216-089-91 RES, CHIP 47K 5% 1/10W
R3540 1-216-049-91 RES, CHIP 1K 5% 1/10W
R3541 1-216-081-00 RES, CHIP 22K 5% 1/10W
R3542 1-216-041-00 RES, CHIP 470 5% 1/10W
R3543 1-216-035-00 RES, CHIP 270 5% 1/10W
R3544 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R3545 1-216-043-91 RES, CHIP 560 5% 1/10W
R3546 1-216-071-00 RES, CHIP 8.2K 5% 1/10W
R3547 1-216-089-91 RES, CHIP 47K 5% 1/10W
R3548 1-216-081-00 RES, CHIP 22K 5% 1/10W
R3549 1-216-049-91 RES, CHIP 1K 5% 1/10W
R3550 1-208-774-11 RES, CHIP 470 0.50% 1/10W
R3551 1-208-764-11 RES, CHIP 180 0.50% 1/10W
R3565 1-216-295-91 SHORT
R3566 1-216-025-91 RES, CHIP 100 5% 1/10W
R3568 1-216-025-91 RES, CHIP 100 5% 1/10W
R3569 1-216-041-00 RES, CHIP 470 5% 1/10W
R3578 1-216-081-00 RES, CHIP 22K 5% 1/10W
R3579 1-216-081-00 RES, CHIP 22K 5% 1/10W
R3580 1-216-295-91 SHORT
R3596 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R3597 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R3599 1-208-774-11 RES, CHIP 470 0.50% 1/10W
CRYSTAL
X3501 1-567-505-11 OSCILLATOR, CRYSTAL
COMPLETE PARTS LISTING
B
