Sony Trinitron KV-35V65 - C COMPLETE PARTS LISTING

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 97 —
C
*A-1331-837-A C BOARD, COMPLETE
(KV-32V40/34VL65C/32V65CND/34VL65/32S40/34SL40/
34SL40C/32S45/34SL45/34SL40T only)
*A-1331-843-A C BOARD, COMPLETE
(KV-35V65CND/37VL65/37VL65C/35S40/35S45/37SL45 only)
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C1750 1-137-528-11 FILM 0.1MF 10% 250V
C1751 1-107-652-11 ELECT 10MF 20% 250V
C1790 1-102-129-00 CERAMIC CHIP 0.01MF 10% 50V
C1791 1-126-968-11 ELECT 100MF 20% 50V
C1792 1-102-108-00 CERAMIC CHIP 150PF 10& 50V
C1794 1-107-651-11 ELECT 4.7MF 20% 250V
(KV-35V65CND/37VL65/37VL65C/35S40/35S45/37SL45 only)
C1795 1-102-074-00 CERAMIC CHIP 0.001MF 10% 50V
C1799 1-162-114-00 CERAMIC CHIP 0.0047MF 2KV
CONNECTOR
CN1761* 1-564-509-11 PLUG, CONNECTOR 6P
CN1764* 1-564-508-11 PLUG, CONNECTOR 5P
CN1765 1-695-915-11 TAB (CONTACT)
DIODE
D1790 8-719-991-33 DIODE 1SS133T-77
D1791 8-719-908-03 DIODE GP08D
D1792 8-719-908-03 DIODE GP08D
(KV-35V65CND/37VL65/37VL65C/35S40/35S45/37SL45 only)
D1793 8-719-908-03 DIODE GP08D
D1794 8-719-908-03 DIODE GP08D
D1795 8-719-908-03 DIODE GP08D
IC
IC1701 8-759-535-08 IC TDA6108Q
JACK
J1761 ¡ 1-251-388-11 SOCKET, CRT
COIL
L1790 1-410-671-31 INDUCTOR 47UH
TRANSISTOR
Q1790 8-729-119-76 TRANSISTOR 2SA1175-HFE
RESISTOR
R1750 1-247-870-11 CARBON 43K 5% 1/4W
R1763 1-260-099-11 CARBON 1K 5% 1/2W
R1764 1-247-807-31 CARBON 100 5% 1/4W
R1773 1-260-099-11 CARBON 1K 5% 1/2W
R1774 1-247-807-31 CARBON 100 5% 1/4W
R1783 1-260-099-11 CARBON 1K 5% 1/2W
R1784 1-247-807-31 CARBON 100 5% 1/4W
R1788 1-216-349-00 METAL OXIDE 1 5% 1W F
R1789 1-249-437-11 CARBON 47K 5% 1/4W
R1790 1-216-378-11 METAL OXIDE 5.6 5% 2W F
(KV-32V40/34VL65C/32V65CND/34VL65/32S40/34SL40/
34SL40C/32S45/34SL45/34SL40T only)
R1790 1-216-369-00 METAL OXIDE 1 5% 2W F
(KV-35V65CND/37VL65/37VL65C/35S40/35S45/37SL45 only)
R1792 1-247-815-91 CARBON 220 5% 1/4W
R1793 1-247-866-11 CARBON 30K 5% 1/4W
R1794 1-260-132-11 CARBON 560K 5% 1/2W
(KV-35V65CND/37VL65/37VL65C/35S40/35S45/37SL45 only)
R1795 1-260-087-11 CARBON 100 5% 1/2W
R1796 1-216-378-11 METAL OXIDE 5.6 5% 2W F
(KV-32V40/34VL65C/32V65CND/34VL65/32S40/34SL40/
34SL40C/32S45/34SL45/34SL40T only)
R1796 1-216-369-00 METAL OXIDE 1 5% 2W F
(KV-35V65CND/37VL65/37VL65C/35S40/35S45/37SL45 only)
R1797 1-260-123-11 CARBON 100K 5% 1/2W
C
COMPLETE PARTS LISTING
Note:
The components identified
with shading and a critical
symbol (
¡¡
¡¡
¡ ) are critical for
safety. Replace only with
part number specified.
Note:
Les composants identifies per
un trame et une marque
¡¡
¡¡
¡ sont
critiques pout la securite. Ne les
remplacer que par une piece
portant le numero specifie.
