Sony Trinitron KV-35V65 - G COMPLETE PARTS LISTING

REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
— 98 —
G
* A-1316-389-A G BOARD, COMPLETE
(KV-32V40/32S40/34SL40/32S45/34SL45 only)
* A-1316-390-A G BOARD, COMPLETE
(KV-34VL65C only)
* A-1316-391-A G BOARD, COMPLETE
(KV-32V65CND/34VL65 only)
* A-1316-395-A G BOARD, COMPLETE
(KV-34SL40C only)
* A-1316-396-A G BOARD, COMPLETE
KV-34SL40T only)
* A-1316-399-A G BOARD, COMPLETE
(KV-35S40/35S45/37SL45 only)
* A-1316-405-A G BOARD, COMPLETE
(KV-35V65CND/37VL65 only)
* A-1316-406-A G BOARD, COMPLETE
(KV-37VL65C only)
1-533-223-11 HOLDER, FUSE
4-382-854-11 SCREW(M3X10), P, SW (+)
CAPACITOR
C601 1-136-346-21 FILM 0.22MF 20% 125V
(KV-35S40/35S45/37SL45/35V65CND/37VL65/37VL65C only)
C602 1-126-964-11 ELECT 10MF 20% 50V
C603 ¡ 1-113-907-51 CERAMIC CHIP 0.0022MF 20% 250V
(KV-34VL65C/34SL40C/37VL65C only)
C603 ¡ 1-113-903-11 CERAMIC 0.001MF 20% 250V
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/34VL65/
35V65CND/37VL65/34SL40T/35S40/35S45/37SL45 only)
C604 ¡ 1-136-346-21 FILM 0.22MF 20% 300V
(KV-34SL40T only)
C605 ¡ 1-136-311-11 FILM 0.47MF 20% 300V
(KV-34VL65C/37VL65C/34SL40C only)
C605 ¡ 1-136-346-21 FILM 0.22MF 20% 125V
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/34VL65/
35V65CND/37VL65/34SL40T/35S40/35S45/37SL45 only)
C606 ¡ 1-117-894-11 ELECT 560MF 20% 250V
C607 ¡ 1-117-894-11 ELECT 560MF 20% 250V
C608 1-165-127-11 CERAMIC CHIP 470PF 10% 500V
C609 1-136-175-00 FILM 0.68MF 5% 50V
C610 1-136-175-00 FILM 0.68MF 5% 50V
C611 1-136-169-00 FILM 0.22MF 5% 50V
(KV-32V40/32S40/34SL40/32S45/34SL45/34SL40C/34SL40T/
35S40/35S45/37VL65 only)
C611 1-136-171-00 FILM 0.33MF 5% 50V
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/
37VL65C only)
C612 1-136-169-00 FILM 0.22MF 5% 50V
(KV-32V40/32S40/34SL40/32S45/34SL45/34SL40C/34SL40T/
35S40/35S45/37VL65 only)
C612 1-136-171-00 FILM 0.33MF 5% 50V
KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
C613 1-164-646-11 CERAMIC CHIP 2200PF 10% 500V
C615 1-129-722-00 FILM 0.047MF 5% 630V
C616 ¡ 1-117-699-11 CERAMIC CHIP 0.001MF 20% 250V
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/34VL65/34SL40T/
35S40/35S45/37SL45/35V65CND/37VL65 only)
C624 1-126-961-11 ELECT 2.2MF 20% 50V
C628 ¡ 1-113-924-11 CERAMIC CHIP 0.0047MF 20% 250V
C629 ¡ 1-107-679-91 ELECT 10MF 20% 450V
(KV-34VL65C/34SL40C/37VL65C only)
C629 ¡ 1-107-680-91 ELECT 22MF 20% 450V
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/34VL65/34SL40T/
35S40/35S45/37SL45/35V65CND/37VL65 only)
C630 1-130-471-00 MYLAR 0.001MF 5% 50V
C631 1-137-605-11 FILM 0.01MF 10% 250V
C633 1-130-471-00 MYLAR 0.001MF 5% 50V
C634 1-130-467-00 MYLAR 470PF 5% 50V
C635 1-130-471-00 MYLAR 0.001MF 5% 50V
C636 1-126-965-11 ELECT 22MF 20% 50V
C637 1-126-940-11 ELECT 330MF 20% 25V
C640 ¡ 1-113-924-11 CERAMIC CHIP 0.0047MF 20% 250V
C641 1-128-550-11 ELECT 2200MF 20% 50V
C643 1-107-641-11 ELECT 220MF 20% 160V
C647 1-104-665-11 ELECT 100MF 20% 25V
C648 1-126-965-11 ELECT 22MF 20% 50V
(KV-37VL65C/34SL40C/34VL65C only)
C650 1-104-664-11 ELECT 47MF 20% 25V
C651 1-137-366-11 FILM 0.0022MF 5% 50V
C652 1-106-351-00 MYLAR 0.0022MF 20% 200V
C653 1-107-636-11 ELECT 10MF 20% 160V
C654 1-164-625-11 CERAMIC CHIP 680PF 10% 500V
C655 1-164-625-11 CERAMIC CHIP 680PF 10% 500V
C656 1-164-625-11 CERAMIC CHIP 680PF 10% 500V
C657 1-164-625-11 CERAMIC CHIP 680PF 10% 500V
C660 1-126-767-11 ELECT 1000MF 20% 16V
C690 1-164-645-11 CERAMIC CHIP 1000PF 10% 500V
C691 1-164-645-11 CERAMIC CHIP 1000PF 10% 500V
G
COMPLETE PARTS LISTING
Note:
The components identified
with shading and a critical
symbol (
¡¡
¡¡
¡ ) are critical for
safety. Replace only with
part number specified.
Note:
Les composants identifies per
un trame et une marque
¡¡
¡¡
¡ sont
critiques pout la securite. Ne les
remplacer que par une piece
portant le numero specifie.
