REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 99 —
CONNECTOR
CN601 1-573-963-11 PIN, CONNECTOR (PC BOARD) 3P
(KV-35S40/35S45/37SL45/35V65CND/37VL65/37VL65C only)
CN602 1-580-844-11 PIN, CONNECTOR (POWER) 2P
CN603 1-573-963-11 PIN, CONNECTOR (PC BOARD) 3P
KV-35S40/35S45/37SL45/35V65CND/37VL65 only)
CN604 1-573-963-11 PIN, CONNECTOR (PC BOARD) 3P
(KV-32V40/32S40/34SL40/32S45/34SL45/34VL65C/32VCND/34VL65/
34SL40C/34SL40T/35S40/35S45/37SL45 only)
CN641 1-564-515-11 PLUG, CONNECTOR 12P
CN643 1-508-784-00 PIN, CONNECTOR (5MM PITCH) 1P
(KV-32V40/32S40/34SL40/32S45/34SL45/34VL65C/32VCND/34VL65/
34SL40C/35S40/35S45/37SL45/35V65CND/35VL65/37VL65C only)
DIODE
D600 ¡ 8-719-991-33 DIODE 1SS133T-77
D601 8-719-991-33 DIODE 1SS133T-77
D602 ¡ 8-719-510-53 DIODE D4SB60L
D603 8-719-052-90 DIODE D1NL40-TA2
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/34VL65/
34SL40T/35S40/35S45/37SL45/35V65CND/37VL65 only)
D604 8-719-052-90 DIODE D1NL40-TA2
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/34VL65/
34SL40T/35S40/35S45/37SL45/35V65CND/37VL65 only)
D612 8-719-991-33 DIODE 1SS133T-77
D613 8-719-991-33 DIODE 1SS133T-77
D614 8-719-991-33 DIODE 1SS133T-77
D621 ¡ 8-719-911-55 DIODE U05G
D622 ¡ 8-719-911-55 DIODE U05G
D623 8-719-055-18 DIODE ERA22-08TP3
D624 8-719-991-33 DIODE 1SS133T-77
D625 8-719-991-33 DIODE 1SS133T-77
(KV-32V40/32S40/34SL40/32S45/34SL45/34VL65C/32V65CND/
34VL65/34SL40C/34SL40T/35S40/35S45/37SL45/37VL65C only)
D626 8-719-109-93 DIODE RD6.2ESB2
D627 8-719-510-48 DIODE D1N20R
D628 8-719-063-70 DIODE D1NL20U
D631 8-719-109-69 DIODE RD3.6ES-B2
(KV-37VL65C/34SL40C/34VL65C only)
D632 8-719-063-70 DIODE D1NL20U-TA2
(KV-37VL65C/34SL40C/34VL65C only)
D641 8-719-052-92 DIODE D10SBS4F
D642 ¡ 8-719-510-12 DIODE D10SC4M
D643 8-719-028-45 DIODE D2L20U
D644 8-719-028-45 DIODE D2L20U
D645 8-719-028-45 DIODE D2L20U
D646 8-719-028-45 DIODE D2L20U
D647 8-719-063-70 DIODE D1NL20U
D648 8-719-057-52 DIODE EZ0150AV1
D649 8-719-510-02 DIODE D1NS4
D650 8-719-510-02 DIODE D1NS4
FUSE
F601 ¡ 1-576-193-11 FUSE 6.3A/125V
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/34VL65/
34SL40T/35S40/35S45/37SL45/35V65CND/37VL65 only)
F601 ¡ 1-532-506-51 FUSE 6.3A/250V
(KV-37VL65C/34SL40C/34VL65C only)
FERRITE BEAD
FB601 1-410-396-41 FERRITE 0.45UH
FB602 1-410-396-41 FERRITE 0.45UH
FB603 1-410-396-41 FERRITE 0.45UH
FB604 1-410-396-41 FERRITE 0.45UH
FB641 1-410-397-21 FERRITE 1.1UH
FB642 1-410-397-21 FERRITE 1.1UH
FB645 1-410-397-21 FERRITE 1.1UH
FB647 1-410-397-21 FERRITE 1.1UH
IC
IC601 ¡ 8-729-041-12 TRANSISTOR MX0841AB-F
IC622 8-759-450-47 IC BA05T
IC641 8-759-198-03 IC PQ09RF21
IC643 8-749-012-13 IC DM-58
COIL
L642 1-412-529-11 INDUCTOR 22UH
TRANSISTOR
Q621 ¡ 8-729-044-30 TRANSISTOR 2SK2845-LB102
Q622 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q644 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q645 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q646 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q647 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q648 8-729-922-39 TRANSISTOR 2SD2144S-V
RESISTOR
R603 ¡ 1-219-776-11 CARBON 2.2M 10% 1/2W
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/
34VL65/34SL40T/35S40/35S45/37SL45/35V65CND/37VL65 only)
R603 ¡ 1-247-289-00 CARBON 8.2M 5% 1W
(KV-34VL65C/34SL40C/37VL65C only)
R607 ¡ 1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R608 ¡ 1-216-373-11 METAL 2.2 5% 2W F
COMPLETE PARTS LISTING
G
Note:
The components identified
with shading and a critical
symbol (
¡¡
¡¡
¡
) are critical for
safety. Replace only with
part number specified.
Note:
Les composants identifies per
un trame et une marque
¡¡
¡¡
¡ sont
critiques pout la securite. Ne les
remplacer que par une piece
portant le numero specifie.
