REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
— 100 —
R611 ¡ 1-216-373-11 METAL 2.2 5% 2W F
R612 1-215-903-11 METAL 68K 5% 2W F
R613 1-215-903-11 METAL 68K 5% 2W F
R614 1-215-903-11 METAL 68K 5% 2W F
R615 1-215-903-11 METAL 68K 5% 2W F
R618 1-249-425-11 CARBON 4.7K 5% 1/4W
R619 1-249-425-11 CARBON 4.7K 5% 1/4W
R620 1-249-425-11 CARBON 4.7K 5% 1/4W
R621 1-249-429-11 CARBON 10K 5% 1/4W
R622 1-247-863-91 CARBON 22K 5% 1/4W
R623 ¡ 1-205-943-11 CEMENTED 1 5% 20W
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/
34VL65/34SL40T/35S40/35S45/37SL45/35V65CND/37VL65 only)
R623 ¡ 1-243-032-11 CEMENTED 3.9 5% 20W
(KV-34VL65C/34SL40C/37VL65C only)
R624 1-260-131-11 CARBON 470K 5% 1/2W
R625 1-260-131-11 CARBON 470K 5% 1/2W
R626 1-249-425-11 CARBON 4.7K 5% 1/4W
R627 ¡ 1-220-797-11 CEMENTED 0.47 5% 10W
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/
34VL65/34SL40T/35S40/35S45/37SL45/35V65CND/37VL65 only)
R628 1-240-205-91 CARBON 22M 5% 1/2W
R629 ¡ 1-220-797-11 CEMENTED 0.47 5% 10W
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/
34VL65/34SL40T/35S40/35S45/37SL45/35V65CND/37VL65 only)
R630 1-215-421-00 METAL 1K 1% 1/4W
(KV-34VL65C/37VL65C/34SL40C only)
R631 1-215-445-00 METAL 10K 1% 1/4W
(KV-34VL65C/37VL65C/34SL40C only)
R632 1-249-421-11 CARBON 2.2K 5% 1/4W
R633 1-249-429-11 CARBON 10K 5% 1/4W
R634 1-249-437-11 CARBON 47K 5% 1/4W
R635 1-247-791-91 CARBON 22 5% 1/4W
R636 1-249-415-11 CARBON 680 5% 1/4W
R637 1-260-302-51 CARBON 6.8 5% 1/2W
R638 1-249-413-11 CARBON 470 5% 1/4W
R639 ¡ 1-249-389-11 CARBON 4.7 5% 1/4W F
R640 1-215-485-00 METAL 470K 1% 1/4W
R640 1-247-895-91 CARBON 470K 5% 1/4W
R641 1-247-843-11 CARBON 3.3K 5% 1/4W
R642 1-247-843-11 CARBON 3.3K 5% 1/4W
R643 1-249-387-11 CARBON 3.3 5% 1/4W F
R648 1-247-887-00 CARBON 220K 5% 1/4W
R649 1-249-425-11 CARBON 4.7K 5% 1/4W F
R659 1-249-429-11 CARBON 10K 5% 1/4W
R660 ¡ 1-249-393-11 CARBON 10 5% 1/4W F
R661 1-249-419-11 CARBON 1.5K 5% 1/4W F
R666 ¡ 1-249-377-11 CARBON 0.47 5% 1/4W F
R667 ¡ 1-249-377-11 CARBON 0.47 5% 1/4W F
R668 ¡ 1-249-377-11 CARBON 0.47 5% 1/4W F
R670 ¡ 1-249-377-11 CARBON 0.47 5% 1/4W F
R671 ¡ 1-249-377-11 CARBON 0.47 5% 1/4W F
R672 ¡ 1-249-377-11 CARBON 0.47 5% 1/4W F
RELAY
RY600 ¡ 1-755-266-11 RELAY, AC POWER
RY601 ¡ 1-755-146-11 RELAY, AC POWER
TRANSFORMER
T601 ¡ 1-426-717-11 TRANSFORMER, LINE FILTER (LFT)
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/
34VL65/34SL40T/35S40/35S45/37SL45/35V65CND/37VL65 only)
T602 ¡ 1-426-717-11 TRANSFORMER, LINE FILTER (LFT)
T603 ¡ 1-429-992-21 TRANSFORMER, CONVERTER (PRT)
T605 ¡ 1-429-415-11 TRANSFORMER, CONVERTER (PIT)
(KV-32V40/32S40/34SL40/32S45/34SL45/34SL40C/34SL40T/35S40/
35S45/37SL45 only)
T605 ¡ 1-431-467-11 TRANSFORMER, CONVERTER (PIT)
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
T621 ¡ 1-431-852-11 TRANSFORMER, CONVEŸbER (SRT)
THERMISTOR
THP601¡ 1-809-539-11 THERMISTOR, POSITIVE
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/
34VL65/35S40/35S45/37SL45/35V65CND/37VL65 only)
THP601¡ 1-809-827-11 THERMISTOR, POSITIVE
(KV-34VL65C/34SL40C/34SL40T/37VL65C only)
VARISTOR
VDR602 1-801-074-41 VARISTOR ERZV10D271
(KV-32V40/32S40/34SL40/32S45/34SL45/32V65CND/
34VL65/34SL40T/35S40/35S45/37SL45/35V65CND/37VL65 only)
VDR602 1-809-267-41 VARISTOR ERZV10D471
(KV-34VL65C/34SL40C/37VL65C only)
Note:
The components identified
with shading and a critical
symbol (
¡¡
¡¡
¡ ) are critical for
safety. Replace only with
part number specified.
Note:
Les composants identifies per
un trame et une marque
¡¡
¡¡
¡ sont
critiques pout la securite. Ne les
remplacer que par une piece
portant le numero specifie.
G
COMPLETE PARTS LISTING
