Sony Trinitron KV-35V65 - K COMPLETE PARTS LISTING

REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
— 104 —
* A-1380-585-A K BOARD, COMPLETE
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
* 1-556-945-21 CABLE, P-P
* 1-557-056-31 CABLE, P-P
* 4-052-905-01 V5/6 BRACKET
8-598-414-00 ANTENNA SWITCH AS-2F
CAPACITOR
C1461 1-126-960-11 ELECT 1MF 20% 50V
C1462 1-126-960-11 ELECT 1MF 20% 50V
C1463 1-126-961-11 ELECT 2.2MF 20% 50V
C1464 1-104-666-11 ELECT 220MF 20% 25V
C1465 1-126-960-11 ELECT 1MF 20% 50V
C1467 1-104-664-11 ELECT 47MF 20% 25V
C1468 1-126-960-11 ELECT 1MF 20% 50V
C1470 1-104-666-11 ELECT 220MF 20% 25V
C1471 1-136-169-00 FILM 0.22MF 5% 50V
C1472 1-136-173-00 FILM 0.47MF 5% 50V
C1473 1-128-550-11 ELECT 2200MF 20% 50V
C1474 1-136-169-00 FILM 0.22MF 5% 50V
C1475 1-128-550-11 ELECT 2200MF 20% 50V
C1476 1-128-550-11 ELECT 2200MF 20% 50V
C1477 1-104-665-11 ELECT 100MF 20% 25V
C1478 1-126-969-11 ELECT 220MF 20% 50V
CONNECTOR
CN1461 * 1-564-508-11 PLUG, CONNECTOR 5P
CN1462 * 1-564-507-11 PLUG, CONNECTOR 4P
CN1463 * 1-564-508-11 PLUG, CONNECTOR 5P
DIODE
D1461 8-719-991-33 DIODE 1SS133T-77
D1462 8-719-979-50 DIODE EGP30D
D1463 8-719-991-33 DIODE 1SS133T-77
D1464 8-719-991-33 DIODE 1SS133T-77
D1465 8-719-991-33 DIODE 1SS133T-77
D1466 8-719-979-50 DIODE EGP30D
D1467 8-719-979-50 DIODE EGP30D
IC
IC1461 8-759-089-13 IC TDA7262
IC LINK
PS1461 1-532-984-11 LINK, IC 2A/90V
TRANSISTOR
Q1461 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1462 8-729-216-22 TRANSISTOR 2SA1162-G
Q1463 8-729-900-53 TRANSISTOR DTC114EK
Q1464 8-729-900-53 TRANSISTOR DTC114EK
Q1465 8-729-216-22 TRANSISTOR 2SA1162-G
RESISTOR
R1461 1-216-061-00 RES, CHIP 3.3K 5% 1/10W
R1462 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1464 1-216-061-00 RES, CHIP 3.3K 5% 1/10W
R1465 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1466 1-216-089-91 RES, CHIP 47K 5% 1/10W
R1467 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1469 1-249-385-11 CARBON 2.2 5% 1/4W F
R1470 1-249-385-11 CARBON 2.2 5% 1/4W F
R1471 1-216-089-91 RES, CHIP 47K 5% 1/10W
R1472 1-216-041-00 RES, CHIP 470 5% 1/10W
R1473 1-216-113-00 RES, CHIP 470K 5% 1/10W
R1474 1-216-077-00 RES, CHIP 15K 5% 1/10W
R1475 1-216-077-00 RES, CHIP 15K 5% 1/10W
R1476 1-247-791-91 CARBON 22 5% 1/4W
R1477 1-249-417-11 CARBON 1K 5% 1/4W F
R1478 1-247-791-91 CARBON 22 5% 1/4W
R1479 1-249-417-11 CARBON 1K 5% 1/4W F
R1480 1-249-421-11 CARBON 2.2K 5% 1/4W
R1481 1-249-421-11 CARBON 2.2K 5% 1/4W
R1482 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1483 1-216-073-00 RES, CHIP 10K 5% 1/10W
R1487 1-216-025-91 RES, CHIP 100 5% 1/10W
R1488 1-216-073-00 RES, CHIP 10K 5% 1/10W
K
COMPLETE PARTS LISTING
K
