Sony Trinitron KV-35V65 - COMPLETE PARTS LISTING P

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 105 —
P
* A-1195-138-A P BOARD, COMPLETE
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
(KV-32S45/34SL45/35S45/37SL45 only)
CAPACITOR
C3319 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C3320 1-126-960-11 ELECT 1MF 20% 50V
C3321 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C3322 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C3323 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C3324 1-104-664-11 ELECT 47MF 20% 16V
C3328 1-104-664-11 ELECT 47MF 20% 16V
C3329 1-104-664-11 ELECT 47MF 20% 16V
C3330 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C3331 1-104-664-11 ELECT 47MF 20% 16V
C3332 1-104-664-11 ELECT 47MF 20% 25V
C3334 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C3335 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C3336 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C3337 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C3340 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C3346 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C3347 1-126-960-11 ELECT 1MF 20% 50V
C3348 1-104-664-11 ELECT 47MF 20% 16V
C3349 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C3350 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C3352 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C3353 1-164-346-11 CERAMIC CHIP 1MF 16V
C3354 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C3355 1-126-925-11 ELECT 470MF 20% 10V
C3356 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C3357 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C3358 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C3359 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C3360 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C3361 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C3362 1-126-925-11 ELECT 470MF 20% 10V
C3363 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C3364 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C3365 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C3366 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C3367 1-126-963-11 ELECT 4.7MF 20% 50V
C3368 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C3369 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C3370 1-164-346-11 CERAMIC CHIP 1MF 16V
C3371 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C3372 1-164-005-11 CERAMIC CHIP 0.47MF 25V
CONNECTOR
CN3301* 1-764-816-11 CONNECTOR, BOARD TO BOARD 20P
IC
IC3302 8-759-231-53 IC TA7805S
IC3303 8-759-533-89 IC SDA9288XE-GEG-B121
IC3304 8-752-086-80 IC CXA2019AQ-T4
COIL
L3301 1-408-607-31 INDUCTOR 22UH
L3302 1-410-473-11 INDUCTOR 18UH
L3303 1-408-612-31 INDUCTOR 56UH
TRANSISTOR
Q3301 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3302 8-729-216-22 TRANSISTOR 2SA1162-G
Q3306 8-729-216-22 TRANSISTOR 2SA1162-G
Q3310 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3312 8-729-216-22 TRANSISTOR 2SA1162-G
Q3314 8-729-216-22 TRANSISTOR 2SA1162-G
RESISTOR
R3301 1-216-295-91 SHORT
R3302 1-216-295-91 SHORT
R3305 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R3312 1-216-037-00 RES, CHIP 330 5% 1/10W
R3313 1-216-295-91 SHORT
R3314 1-216-049-91 RES, CHIP 1K 5% 1/10W
R3323 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R3329 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R3330 1-216-295-91 SHORT
R3337 1-216-033-00 RES, CHIP 220 5% 1/10W
R3338 1-216-033-00 RES, CHIP 220 5% 1/10W
R3339 1-216-049-91 RES, CHIP 1K 5% 1/10W
R3340 1-216-041-00 RES, CHIP 470 5% 1/10W
R3341 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R3342 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R3343 1-216-049-91 RES, CHIP 1K 5% 1/10W
R3346 1-216-049-91 RES, CHIP 1K 5% 1/10W
R3351 1-216-295-91 SHORT
R3352 1-216-049-91 RES, CHIP 1K 5% 1/10W
COMPLETE PARTS LISTING
P
