Sony Trinitron KV-35V65 - COMPLETE PARTS LISTING UV

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 107 —
COMPLETE PARTS LISTING
UV
UV
* A-1394-905-A UV BOARD, COMPLETE
(KV-32V40 only)
* A-1394-906-A UV BOARD, COMPLETE
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
CAPACITOR
C100 1-164-346-11 CERAMIC CHIP 1MF 16V
C101 1-165-319-11 CERAMIC CHIP 0.1MF 50V
C102 1-164-346-11 CERAMIC CHIP 1MF 16V
C103 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C104 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C105 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C150 1-126-956-91 ELECT 0.1MF 20% 50V
C153 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C154 1-126-963-11 ELECT 4.7MF 20% 50V
C155 1-126-963-11 ELECT 4.7MF 20% 50V
C156 1-126-963-11 ELECT 4.7MF 20% 50V
C158 1-126-963-11 ELECT 4.7MF 20% 50V
C160 1-126-964-11 ELECT 10MF 20% 50V
C161 1-126-956-91 ELECT 0.1MF 20% 50V
C162 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C163 1-104-664-11 ELECT 47MF 20% 25V
C164 1-165-319-11 CERAMIC CHIP 0.1MF 50V
C165 1-126-964-11 ELECT 10MF 20% 50V
C168 1-126-963-11 ELECT 4.7MF 20% 50V
C171 1-126-941-11 ELECT 470MF 20% 25V
C172 1-126-959-11 ELECT 0.47MF 20% 50V
C173 1-126-959-11 ELECT 0.47MF 20% 50V
C174 1-126-964-11 ELECT 10MF 20% 50V
C176 1-126-964-11 ELECT 10MF 20% 50V
C177 1-126-964-11 ELECT 10MF 20% 50V
C178 1-126-964-11 ELECT 10MF 20% 50V
C179 1-164-182-11 CERAMIC CHIP 0.0033MF 10% 50V
C180 1-164-182-11 CERAMIC CHIP 0.0033MF 10% 50V
C181 1-163-989-11 CERAMIC CHIP 0.033MF 10% 25V
C182 1-163-989-11 CERAMIC CHIP 0.033MF 10% 25V
C183 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C184 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C185 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C187 1-126-964-11 ELECT 10MF 20% 50V
C188 1-126-956-91 ELECT 0.1MF 20% 50V
C189 1-126-956-91 ELECT 0.1MF 20% 50V
C190 1-163-986-00 CERAMIC CHIP 0.027MF 10% 25V
C191 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C192 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C193 1-165-319-11 CERAMIC CHIP 0.1MF 50V
C194 1-163-023-00 CERAMIC CHIP 0.015MF 10% 50V
C195 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V
C196 1-126-965-11 ELECT 22MF 20% 50V
C197 1-165-319-11 CERAMIC CHIP 0.1MF 50V
C198 1-126-960-11 ELECT 1MF 20% 50V
C199 1-165-319-11 CERAMIC CHIP 0.1MF 50V
C231 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C232 1-136-161-00 FILM 0.047MF 5% 50V
C233 1-136-161-00 FILM 0.047MF 5% 50V
C234 1-126-960-11 ELECT 1MF 20% 50V
C235 1-126-960-11 ELECT 1MF 20% 50V
C236 1-136-161-00 FILM 0.047MF 5% 50V
C237 1-126-960-11 ELECT 1MF 20% 50V
C238 1-126-960-11 ELECT 1MF 20% 50V
C241 1-126-941-11 ELECT 470MF 20% 25V
C242 1-126-959-11 ELECT 0.47MF 20% 50V
C244 1-126-959-11 ELECT 0.47MF 20% 50V
C245 1-126-941-11 ELECT 470MF 20% 25V
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
C246 1-126-959-11 ELECT 0.47MF 20% 50V
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
C247 1-126-959-11 ELECT 0.47MF 20% 50V
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
C261 1-136-161-00 FILM 0.047MF 5% 50V
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
C262 1-104-664-11 ELECT 47MF 20% 25V
C263 1-136-161-00 FILM 0.047MF 5% 50V
C264 1-126-941-11 ELECT 470MF 20% 25V
C266 1-126-960-11 ELECT 1MF 20% 50V
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
C267 1-126-960-11 ELECT 1MF 20% 50V
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
C270 1-126-960-11 ELECT 1MF 20% 50V
C271 1-126-960-11 ELECT 1MF 20% 50V
C275 1-104-664-11 ELECT 47MF 20% 25V
C276 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
CONNECTOR
CN261 1-691-632-21 CONNECTOR, BOARD TO BOARD 15P
CN262 1-573-301-21 CONNECTOR, BOARD TO BOARD 20P
CN263 * 1-564-506-11 PLUG, CONNECTOR 3P
CN264 1-573-979-21 CONNECTOR, BOARD TO BOARD 11P
CN265 1-564-508-11 PLUG, CONNECTOR 5P
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
