REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
— 108 —
Note:
The components identified
with shading and a critical
symbol (
¡¡
¡¡
¡ ) are critical for
safety. Replace only with
part number specified.
Note:
Les composants identifies per
un trame et une marque
¡¡
¡¡
¡ sont
critiques pout la securite. Ne les
remplacer que par une piece
portant le numero specifie.
DIODE
D100 8-719-981-99 DIODE MTZJ-3.3
D231 8-719-110-17 DIODE RD10ESB2
D232 8-719-110-17 DIODE RD10ESB2
D233 8-719-110-17 DIODE RD10ESB2
D234 8-719-110-17 DIODE RD10ESB2
D235 8-719-110-17 DIODE RD10ESB2
D236 8-719-110-17 DIODE RD10ESB2
D237 8-719-981-99 DIODE MTZJ-3.3
D238 8-719-981-99 DIODE MTZJ-3.3
D239 8-719-981-99 DIODE MTZJ-3.3
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/
37VL65Conly)
D240 8-719-110-17 DIODE RD10ESB2
D241 8-719-110-17 DIODE RD10ESB2
D242 8-719-110-17 DIODE RD10ESB2
D243 8-719-110-17 DIODE RD10ESB2
D244 8-719-110-17 DIODE RD10ESB2
D245 8-719-981-99 DIODE MTZJ-3.3
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/
37VL65C only)
D246 8-719-981-99 DIODE MTZJ-3.3
D264 8-719-110-17 DIODE RD10ESB2
D265 8-719-110-17 DIODE RD10ESB2
D902 8-719-110-17 DIODE RD10ESB2
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/
37VL65C only)
IC
IC100 8-752-072-39 IC CXA2021S
IC101 8-759-100-96 IC UPC4558G2
IC102 8-759-537-25 IC NJM2150M
IC103 8-759-537-26 IC TDA7467D
IC261 8-759-366-77 IC MM1311AD
(KV-32V40 only)
IC261 8-759-534-81 IC MM1313AD
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/
37VL65C only)
JACK
J231 1-750-515-11 TERMINAL BLOCK, S 3P
J232 1-750-517-11 JACK BLOCK, PIN 3P
J233 1-750-516-11 JACK BLOCK, PIN 2P
J234 1-750-517-11 JACK BLOCK, PIN 3P
J235 1-750-517-11 JACK BLOCK, PIN 3P
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/
37VL65C only)
J902 1-764-143-11 JACK 3P
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
J903 1-764-143-11 JACK 3P
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
J904 1-764-143-11 JACK 3P
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
CHIP CONDUCTOR
JR101 1-216-295-91 SHORT
(KV-32V40 only)
JR106 1-216-295-91 SHORT
JR107 1-216-295-91 SHORT
JR109 1-216-295-91 SHORT
(KV-32V40 only)
JR201 1-216-295-91 SHORT
JR204 1-216-295-91 SHORT
JR205 1-216-295-91 SHORT
JR269 1-216-295-91 SHORT
JR270 1-216-295-91 SHORT
JR272 1-216-295-91 SHORT
JR273 1-216-295-91 SHORT
JR274 1-216-295-91 SHORT
JR276 1-216-295-91 SHORT
JR901 1-216-295-91 SHORT
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
TRANSISTOR
Q100 8-729-422-27 TRANSISTOR 2SD601A-Q
Q101 8-729-422-27 TRANSISTOR 2SD601A-Q
Q231 8-729-422-27 TRANSISTOR 2SD601A-Q
Q232 8-729-422-27 TRANSISTOR 2SD601A-Q
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
Q233 8-729-422-27 TRANSISTOR 2SD601A-Q
Q234 8-729-422-27 TRANSISTOR 2SD601A-Q
Q235 8-729-422-27 TRANSISTOR 2SD601A-Q
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
Q236 8-729-422-27 TRANSISTOR 2SD601A-Q
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
Q237 8-729-216-22 TRANSISTOR 2SA1162-G
Q238 8-729-216-22 TRANSISTOR 2SA1162-G
Q239 8-729-216-22 TRANSISTOR 2SA1162-G
Q240 8-729-216-22 TRANSISTOR 2SA1162-G
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
Q241 8-729-216-22 TRANSISTOR 2SA1162-G
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
Q242 8-729-216-22 TRANSISTOR 2SA1162-G
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
Q243 8-729-216-22 TRANSISTOR 2SA1162-G
COMPLETE PARTS LISTING
UV
