REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 109 —
Note:
The components identified
with shading and a critical
symbol (
¡¡
¡¡
¡
) are critical for
safety. Replace only with
part number specified.
Note:
Les composants identifies per
un trame et une marque
¡¡
¡¡
¡ sont
critiques pout la securite. Ne les
remplacer que par une piece
portant le numero specifie.
Q261 8-729-422-27 TRANSISTOR 2SD601A-Q
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
Q262 8-729-422-27 TRANSISTOR 2SD601A-Q
Q263 8-729-216-22 TRANSISTOR 2SA1162-G
Q265 8-729-216-22 TRANSISTOR 2SA1162-G
RESISTOR
R100 1-216-033-00 RES, CHIP 220 5% 1/10W
R101 1-216-033-00 RES, CHIP 220 5% 1/10W
R102 1-216-073-00 RES, CHIP 10K 5% 1/10W
R103 1-216-093-00 RES, CHIP 68K 5% 1/10W
R104 1-216-089-91 RES, CHIP 47K 5% 1/10W
R105 1-216-089-91 RES, CHIP 47K 5% 1/10W
R106 1-216-049-91 RES, CHIP 1K 5% 1/10W
R107 1-216-049-91 RES, CHIP 1K 5% 1/10W
R108 1-216-073-00 RES, CHIP 10K 5% 1/10W
R109 1-216-089-91 RES, CHIP 47K 5% 1/10W
R110 1-216-089-91 RES, CHIP 47K 5% 1/10W
R111 1-216-025-91 RES, CHIP 100 5% 1/10W
R112 1-216-121-91 RES, CHIP 1M 5% 1/10W
R113 1-216-081-00 RES, CHIP 22K 5% 1/10W
R114 1-216-081-00 RES, CHIP 22K 5% 1/10W
R115 1-216-081-00 RES, CHIP 22K 5% 1/10W
R116 1-216-081-00 RES, CHIP 22K 5% 1/10W
R117 1-216-073-00 RES, CHIP 10K 5% 1/10W
R118 1-216-073-00 RES, CHIP 10K 5% 1/10W
R119 1-216-073-00 RES, CHIP 10K 5% 1/10W
R124 1-216-033-00 RES, CHIP 220 5% 1/10W
R125 1-216-033-00 RES, CHIP 220 5% 1/10W
R126 1-216-063-91 RES, CHIP 3.9K 5% 1/10W
R127 1-216-089-91 RES, CHIP 47K 5% 1/10W
R128 1-216-085-00 RES, CHIP 33K 5% 1/10W
R129 1-216-053-00 RES, CHIP 1.5K 5% 1/10W
R130 1-216-100-00 RES, CHIP 130K 5% 1/10W
R131 1-216-049-91 RES, CHIP 1K 5% 1/10W
R132 1-216-088-00 RES, CHIP 43K 5% 1/10W
R133 1-216-061-00 RES, CHIP 3.3K 5% 1/10W
R134 1-216-061-00 RES, CHIP 3.3K 5% 1/10W
R135 1-216-097-91 RES, CHIP 100K 5% 1/10W
R136 1-216-093-00 RES, CHIP 68K 5% 1/10W
R137 1-216-025-91 RES, CHIP 100 5% 1/10W
R141 1-216-295-91 SHORT
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R142 1-216-295-91 SHORT
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R201 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R202 1-216-049-91 RES, CHIP 1K 5% 1/10W
R203 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R204 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R206 1-216-049-91 RES, CHIP 1K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R207 1-216-295-91 SHORT
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R208 1-216-049-91 RES, CHIP 1K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R209 1-216-069-00 RES, CHIP 6.8K 5% 14W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R210 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R212 1-249-440-11 CARBON 82K 5% 1/4W
R213 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R214 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R215 1-249-413-11 CARBON 470 5% 1/4W
R216 1-216-025-91 RES, CHIP 100 5% 1/10W
R217 1-216-025-91 RES, CHIP 100 5% 1/10W
R218 1-216-025-91 RES, CHIP 100 5% 1/10W
R219 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R220 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R221 1-249-413-11 CARBON 470 5% 1/4W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R222 1-216-025-91 RES, CHIP 100 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R223 1-216-025-91 RES, CHIP 100 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R224 1-216-025-91 RES, CHIP 100 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R225 1-247-815-91 CARBON 220 5% 1/4W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R226 1-247-815-91 CARBON 220 5% 1/4W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R227 1-249-440-11 CARBON 82K 5% 1/4W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R228 1-216-033-00 RES, CHIP 220 5% 1/10W
R229 1-216-025-91 RES, CHIP 100 5% 1/10W
R230 1-216-033-00 RES, CHIP 220 5% 1/10W
R231 1-216-022-00 RES, CHIP 75 5% 1/10W
R232 1-216-022-00 RES, CHIP 75 5% 1/10W
R233 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R234 1-216-022-00 RES, CHIP 75 5% 1/10W
R235 1-216-113-00 RES, CHIP 470K 5% 1/10W
COMPLETE PARTS LISTING
