REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
— 110 —
R236 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R237 1-216-113-00 RES, CHIP 470K 5% 1/10W
R238 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R239 1-216-022-00 RES, CHIP 75 5% 1/10W
R240 1-216-113-00 RES, CHIP 470K 5% 1/10W
R241 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R242 1-216-113-00 RES, CHIP 470K 5% 1/10W
R243 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R244 1-216-113-00 RES, CHIP 470K 5% 1/10W
R245 1-249-417-11 CARBON 1K 5% 1/4W
R246 1-216-113-00 RES, CHIP 470K 5% 1/10W
R247 1-249-417-11 CARBON 1K 5% 1/4W
R248 1-216-021-00 RES, CHIP 68 5% 1/10W
R249 1-216-113-00 RES, CHIP 470K 5% 1/10W
R250 1-216-113-00 RES, CHIP 470K 5% 1/10W
R251 1-216-113-00 RES, CHIP 470K 5% 1/10W
R252 1-216-019-00 RES, CHIP 56 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R253 1-216-113-00 RES, CHIP 470K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R254 1-216-113-00 RES, CHIP 470K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R255 1-216-113-00 RES, CHIP 470K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R256 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R258 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R259 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R260 1-247-807-31 CARBON 100 5% 1/4W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R261 1-216-009-00 RES, CHIP 22 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R264 1-247-815-91 CARBON 220 5% 1/4W
R265 1-247-815-91 CARBON 220 5% 1/4W
R266 1-216-043-91 RES, CHIP 560 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R267 1-249-415-11 CARBON 680 5% 1/4W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R268 1-216-025-91 RES, CHIP 100 5% 1/10W
R269 1-216-025-91 RES, CHIP 100 5% 1/10W
R270 1-216-041-00 RES, CHIP 470 5% 1/10W
R271 1-249-415-11 CARBON 680 5% 1/4W
R272 1-249-417-11 CARBON 1K 5% 1/4W
R274 1-249-413-11 CARBON 470 5% 1/4W
R275 1-249-425-11 CARBON 4.7K 5% 1/4W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R276 1-249-425-11 CARBON 4.7K 5% 1/4W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R277 1-216-049-91 RES, CHIP 1K 5% 1/10W
R278 1-249-413-11 CARBON 470 5% 1/4W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R279 1-216-025-91 RES, CHIP 100 5% 1/10W
R280 1-216-033-00 RES, CHIP 220 5% 1/10W
R281 1-216-033-00 RES, CHIP 220 5% 1/10W
R282 1-216-025-91 RES, CHIP 100 5% 1/10W
R283 1-216-025-91 RES, CHIP 100 5% 1/10W
R284 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R285 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R286 1-216-049-91 RES, CHIP 1K 5% 1/10W
R288 1-247-815-91 CARBON 220 5% 1/4W
R289 1-247-815-91 CARBON 220 5% 1/4W
R290 1-247-815-91 CARBON 220 5% 1/4W
R291 1-216-025-91 RES, CHIP 100 5% 1/10W
R292 1-216-025-91 RES, CHIP 100 5% 1/10W
(KV-32V40 only)
R293 1-216-025-91 RES, CHIP 100 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R294 1-216-049-91 RES, CHIP 1K 5% 1/10W
R902 1-249-405-11 CARBON 100 5% 1/4W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R919 1-216-295-91 SHORT
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R920 1-249-405-11 CARBON 100 5% 1/4W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R921 1-249-405-11 CARBON 100 5% 1/4W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R922 1-216-049-91 RES, CHIP 1K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R923 1-216-049-91 RES, CHIP 1K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
R924 1-216-049-91 RES, CHIP 1K 5% 1/10W
(KV-34VL65C/32V65CND/34VL65/35V65CND/37VL65/37VL65C only)
COMPLETE PARTS LISTING
