Specifications
31
Specifications
General
PVM-9L3/PVM-9L2
CRT: HR Trinitron, P22 luminescent
material (PVM-9L3)
Trinitron, P22 luminescent material
(PVM-9L2)
Power: AC100 to 240 V, 50/60 Hz
Power consumption:
Maximum 58 W, 0.6 to 0.3 A (when the
BKM-150CP optional board has
been installed) 12 V DC, 4.2 A,
48 W
Standard: 47 W, 0.5 to 0.25 A (Without
optional board) 12 V DC, 3.3 A, 38 W
Peak inrush current:
(1) Power ON, current probe method:
70 A (240 V)
(2) Hot switching inrush current,
measured in accordance with
European standard EN55103-1:
12 A (230 V)
Dimensions (max.):
Approx. 217 × 218 × 373 mm
(8
5
/
8
× 8
5
/
8
× 14
3
/
4
inches)
(w/h/d)
Mass: Approx. 8.0 kg (17 lb 10 oz)
PVM-14L2
CRT: Trinitron, P22 luminescent material
Power: AC100 to 240 V, 50/60 Hz
Power consumption:
Maximum 85 W, 0.9 to 0.4 A (when the
BKM-150CP optional board has
been installed)
Standard: 75 W, 0.8 to 0.35 A (Without
optional board)
Peak inrush current:
(1) Power ON, current probe method:
53 A (240 V)
(2) Hot switching inrush current,
measured in accordance with
European standard EN55103-1:
35 A (230 V)
Dimensions (max.):
Approx. 346 × 340 × 430 mm
(13
5
/
8
× 13
1
/
2
× 17 inches)
(w/h/d)
Mass: Approx. 18.0 kg (39 lb 11 oz)
PVM-20L2
CRT: Trinitron, P22 luminescent material
Power: AC100 to 240 V, 50/60 Hz
Power consumption:
Maximum 108 W, 1.1 to 0.5 A (when
the BKM-150CP optional board has
been installed)
Standard: 98 W, 1.0 to 0.4 A (Without
optional board)
Peak inrush current:
(1) Power ON, current probe method:
53 A (240 V)
(2) Hot switching inrush current,
measured in accordance with
European standard EN55103-1:
35 A (230 V)
Dimensions (max.):
Approx. 453 × 463 × 529 mm
(17
7
/
8
× 18
1
/
4
× 20
7
/
8
inches)
(w/h/d)
Mass: Approx. 33.0 kg (72 lb 12 oz)
Input/output connectors
Input
LINE A input connectors
Y/C input 4-pin mini-DIN (1)
VIDEO input
BNC type (1) 1 Vp-p +3 dB –6 dB
negative synchronization
AUDIO input
Phono jack (1) –5 dBu 47 kΩ or higher
LINE B input connectors
VIDEO input
BNC type (1) 1 Vp-p +3 dB –6 dB
negative synchronization
AUDIO input
Phono jack (1) –5 dBu 47 kΩ or higher
RGB/Component input connectors
BNC type (3) (for the PVM-14L2/
PVM-20L2 only)
RGB input 0.7 Vp-p +3 dB –6 dB (Sync On Green,
0.3 Vp-p negative sync.)
Component input
0.7 Vp-p +3 dB –6 dB (75%
chrominance standard color bar
signal)
AUDIO input
Phono jack (1) –5 dBu 47 kΩ or higher
Externally synchronized input connector
BNC type (1) 0.3 to 8 Vp-p
± bipolarity ternary or negative
polarity binary
Optional AUDIO input jacks
Phono jack (2) –5 dBu 47 kΩ or higher

Sony Trinitron PVM-14L2 Specifications

General

Screen Size	14 inches
Display Type	CRT
Aspect Ratio	4:3
Weight	15.4 kg
CRT Type	Trinitron
Input Connectors	S-Video
Audio Inputs	RCA
