Sony Trinitron PVM-20M2MDE - Page 37

37
Pin assignment
Y/C IN connector (4-pin mini-DIN)
Signal
Y-input
CHROMA
subcarrier-input
GND for Y-input
GND for
CHROMA-input
Description
1 Vp-p, sync negative,
75 ohms
300m Vp-p (PAL)/286m
Vp-p (NTSC), burst
Delay time between Y
and C: within 0 ± 100
nsec., 75 ohms
GND
GND
Pin No.
1
2
3
4
21
34
*
RS-232C (D-sub 9-pin)
12345
6789
Pin No.
1
2
3
4
5
6
7
8
9
Signal
—
RX
TX
—
GND
—
RTS
CTS
—
REMOTE 1 (8-pin mini DIN)
8
5
7
6
4
3
1
2
Pin No.
1
2
3
4
5
6
7
8
Signal
REMOTE ON/OFF
LINE A
GND
LINE B
TALLY
OVER SCAN
RGB A
RGB B
