5-1. The Barcode Label
The hatched portion of the barcode label is used as the repair data.
ࡃ࡯ࠦ࡯࠼࡜ࡌ࡞ߩ✂ដߌㇱߪ㧘ୃℂ࠺࡯࠲ߣߒߡ૶↪޿ߚߒ߹ߔޕ
A : Part No.
B : Serial No.
C : Revision No.
D : Product Code
E : Maker Barcode
F : Global User ID (iLink)
G: Mac Address
: Barcode
[MBX-138 Board]
(Side A)
[LCD Unit]
(Front)
[Keyboard Unit]
(Rear)
[W-LAN Card intel]
[MODEM Card]
[Drive COMBO/RW/SM)
(Rear)
[HDD]
(Rear)
[MEMORY]
A,B
C
D
D
D
D
[W-LAN Card Atheros]
D
D
D
[WAN Module]
(Top)
D
D
[WAN Module]
(Rear)
D
[MA]
2
[MA]
2
