Sony VGN-TX50B - Table of Contents; Section Title

- 3 -
VGN-TX50B/TX70PZ/TX90PS/TX90S (J)
VGN-TX610P/TX630P/TX650P/TX651P/TX670P/TX690P (AM)
VGN-TX1HP/TX1XP/TX1XRP (EU)
VGN-TX15C/TX16C/TX16GP/TX16SP/TX16TP/TX17C/TX17GP/TX17TP (AO)
Sony Confidential
TABLE OF CONTENTS
Section Title Page
CHAPTER 1. SPECIFICATIONS
1-1. Specifications .................................................................................................................................... 1-1
(to 1-2)
CHAPTER 2. BLOCK DIAGRAM .............................................................................................. 2-1
(to 2-1)
CHAPTER 3. FRAME HARNESS DIAGRAM ..................................................................... 3-1
(to 3-1)
CHAPTER 4. EXPLODED VIEWS AND PARTS LIST
How to identify the VGN-TX90PS ...............................................................................................4-2
Palmrest
P- 1 ......................................................................................................................................................... 4-3
Main Board
M-1 ........................................................................................................................................................ 4-5
Bottom
B-1 ......................................................................................................................................................... 4-7
LCD
L-1. 11.1/WXGA HDAR/BR (To) .................................................................................................... 4-9
Accessories
A-1 ...................................................................................................................................................... 4-11
(to 4-11)
History of the changes is shown as the
“Revision History” at the end of this data.
ᄌᦝጁᱧߪޔ“ Revision History ” ߣߒߡޔ
ᧄ࠺࡯࠲ᧃߦ⸥タߒߡ޽ࠅ߹ߔޕ
Section Title Page
CHAPTER 5. OTHERS
5-1. The Barcode Label ........................................................................................................................... 5-1
5-2. Precautions for Handling the Drive .............................................................................................. 5-2
5-3. Note for WWAN Board Replacement .......................................................................................... 5-3
(to 5-3)
[MA]
2
