52
Specifications
INPUT OUTPUT
(Computer/video)
INPUT A RGB/YPBPR input connector: Mini D-sub 15-pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative,
75 ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB,
75 ohms terminated, Sync signal: TTL level high
impedance, positive/negative
Audio input connector (VPL-EW276/EW246/EW226/
EX276/EX246/EX226 only): Stereo mini jack, rated
input 500 mVrms, input impedance more than 47 kohms
INPUT B RGB input connector: Mini D-sub 15-pin female,
RGB: 0.7 Vp-p ± 2 dB, 75 ohms terminated, Sync signal:
TTL level high impedance, positive/negative
Audio input connector (VPL-EW276/EW246/EW226/
EX276/EX246/EX226 only): Stereo mini jack, rated
input 500 mVrms, input impedance more than 47 kohms
INPUT C HDMI input connector (Audio output is available
only on VPL-EW276/EW246/EW226/EX276/EX246/
EX226.): HDMI 19-pin, HDCP, HDMI audio support
S VIDEO
(SVIDEO IN)
S video input connector: Mini DIN 4-pin, Y: 1 Vp-p
± 2dB, sync negative, 75 ohms terminated, C: (burst
signal) 0.286 (NTSC)/0.3 (PAL/SECAM) Vp-p ± 2 dB,
75 ohms terminated
Audio input connector (VPL-EW276/EW246/EW226/
EX276/EX246/EX226 only): Phono jack × 2, rated
input 500 mVrms, input impedance more than 47 kohms
VIDEO (VIDEO
IN)
Video input connector: Pin jack, 1 Vp-p ± 2 dB, sync
negative, 75 ohms terminated
Audio input connector (VPL-EW276/EW246/EW226/
EX276/EX246/EX226 only): Shared with S VIDEO
OUTPUT MONITOR output connector: Mini D-sub 15-pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative,
75 ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB,
75 ohms terminated, Sync signal: HD, VD 4 V (open),
1 Vp-p (75 ohms), positive/negative
Audio output connector (VPL-EW276/EW246/
EW226/EX276/EX246/EX226 only): Stereo mini jack,
1 Vrms (maximum volume, when inputting 500 mVrms),
output impedance 5 kohms
Other connectors RS-232C connector: D-Sub 9-pin male
LAN connector: RJ45, 10BASE-T/100BASE-TX
USB connector: Type A
USB connector: Type B
Microphone input (VPL-EW276/EW246/EW226/
EX276/EX246/EX226 only): Mini jack
Operating
temperature/
Operating
humidity
0 °C to 40 °C (32 °F to 104 °F)/35% ~ 85% (no
condensation)
Items Descriptions
Model VPL-EW276/EW246/EW226/EX276/EX272/EX246/EX242/
EX226/EX222
